Bobcat T190 skid steer is a heavy-duty bobcat loader designed to go the distance while delivering superior performance through its diesel engine, new transmission, and four-speed powershift transmission. If you’re looking for a compact skid steer loader, then this model is for you.
Bobcat T190 Specs
The following is a detailed review of the Bobcat T190 skid steer, along with its specifications.
| Manufacturer | Bobcat |
| Model | T190 |
| Type | Compact track loader |
| Serial Numbers | S/N 531660001 & Above S/N 531760001 & Above |
| Years Made | 2004-2007 |
Engine
| Brand | Kubota |
| Model | V2403M |
| Type | Diesel liquid |
| Emission | Tier 2 |
| No of Cylinders | 4 |
| Rated Power | 2800 rpm |
| US | Metric | |
|---|---|---|
| Horsepower | 66.0 HP | 49.2 kW |
| Displacement | 148 cu in. | 2430 cc |
| Bore and Stroke | 3.4 x 4.0 in. | 8.7×10.2 cm |
| Engine Oil Capacity | 2.3 gal | 8.7 L |
Performance
| US | Metric | |
|---|---|---|
| Rating Operating Capacity (ROC 35% Tipping) | 1900 lbs | 862 kg |
| Tipping Load | 6850 lbs | 3108 kg |
| Bucket Capacity | 0.6 cu. yds | 458 L |
| Travel Speed | 7.1 mph | 11.0 km |
| Ground Pressure | 4.9 psi | 33.8 kpa |
Hydraulic System
| US | Metric | |
|---|---|---|
| Standard Flow | 16.3 GPM | 62.0 LPM |
| High Flow | 25.5 GPM | 96.4 LPM |
| System Relief Pressure | 3300 psi | 227 Bar |
Fluid Capacities
| US | Metric | |
|---|---|---|
| Fuel Tank Capacity | 28 gal | 106 L |
| Cooling Capacity | 3 gal | 11 L |
| Hydraulic Capacity | 9 gal | 34 L |
Weight
| US | Metric | |
|---|---|---|
| Operating Weight | 7612 lbs | 3453 kg |
Dimensions
| US | Metric | |
|---|---|---|
| Bucket Hinge Pin | 118 in. | 300 cm |
| Height | 76 in. | 193 cm |
| Width | 66 in. | 168 cm |
| Lenght | 130 in. | 331 cm |
Undercarriage
| Number of Track Rollers per Side | 4 |
| Track Gauge | 4.5 ft |
| Width of Track | 12.6 in. |
The Bobcat T190 skid steer is a machine that deserves to be given an in-depth look. It is certainly one of the best machines that Bobcat has ever created.
If you’re looking for a big piece of equipment that can move a lot of material at once, you might want to look elsewhere. But if you’re looking for a tool that’s compact enough to handle small lifting jobs, this is the perfect tool.
The Bobcat T190 skid steer is a machine that deserves careful consideration. It is without a doubt one of the best machines Bobcat has ever produced.
The Bobcat T190 is dependable. This high-performance skid steer loader will provide you with the power and efficiency you require to complete all of your tasks more quickly and efficiently.
If you need a large piece of equipment that can move a lot of material at once, you should look elsewhere. However, if you need a tool that is small enough to handle small lifting jobs, this is the tool for you.Bobcat T190 Review
