Takeuchi tb240 is a commonly used mini excavator that is effective in jobs such as landscaping, excavation, demolition, and more. The tb240 Takeuchi excavator is a multi-purpose hydraulic excavator that handles a wide range of applications. With superior digging and digging power, you can get the job done with ease. This outstanding, compact excavator delivers a powerful low- and mid-range drive, increased capacity, and durability in a comfortable, ergonomic cab design. Bring your ideas to life with the productivity of the Takeuchi tb240.
Takeuchi TB240’s sturdy construction and powerful hydraulics make it exceptionally dependable, year after year, job after job. The reduced number of hydraulic cylinders makes maintenance easier, while the convenient remote-mount specifications save time on set-up.
Takeuchi Tb240 Specs
Brand | Takeuchi |
Model | Tb240 |
Series | TB series |
Type | Mini excavator |
Serial Numbers | 124000003- ……. 124100002- ……. |
Years Made | 2014-2022 |
Engine Specs
Brand | Yanmar |
Engine Model No | 4TNV88 |
Type | Diesel |
No. of Cylinders | 4 |
Aspiration | N/A |
Aftertreatment | DPF |
Emissions | Tier 4 |
Combustion | Direct injection |
Rated Speed | 2200 RPM |
Max. Torque | 1430 RPM |
Max. Idle Power | 3000 RPM |
US | Metric | |
---|---|---|
Horsepower | 35.8 HP | 26.7 kW |
Torque Power | 145 ft-lb | 197 N-m |
Displacement | 133.6 cu in. | 2189 cc |
Bore and Stroke | 3.46×3.54 in. | 8.8 x 9.0 cm |
Lubrication | 1.95 gal | 7.4 L |
Cooling System | 2.4 gal | 9.0 L |
Fuel Tank Capacity | 18.5 gal | 70.0 L |
Engine Dimensions
US | Metric | |
---|---|---|
Length | 34.3 in. | 87.1 cm |
Width | 21.3 in. | 54.1 cm |
Height | 28.1 in. | 71.4 cm |
Engine Weight
US | Metric | |
---|---|---|
Dry Weight | 452 Ibs | 205 kg |
Performance
US | Metric | |
---|---|---|
Breakout Force Bucket | 9,959 lbs | 4517 kg |
Max. Digging Depth | 130.5 in. | 331.5 cm |
Max. Vertical Digging Depth | 99.4 in. | 252.5 cm |
Max. Height of Cutting Edge | 203 in. | 515 cm |
Max. Dumping Height | 147 in. | 373 cm |
Slew Radius | 53.5 in. | 136 cm |
Bucket Capacity | 1.29 ft² | 0.12 m² |
Ground Pressure (cab) | 4.58 psi | 31.6 kPa |
Ground Pressure (canopy) | 4.37 psi | 30.1 kPa |
Max. Arm Digging Force (145 cm arm) | 4409 lbs | 2000 kg |
Max. Arm Digging Force (160 cm arm) | 4114 lbs | 1866 kg |
Traction Force | 9532 lbs | 4325 kg |
Hydraulic Pressure | 2987 psi | 20.6 MPa |
Swing Angle
Right | 57° |
Left | 77° |
Travel Speed
US | Metric | |
---|---|---|
Low Speed | 4.4 mph | 7.1 km |
High Speed | 6.3 mph | 10.1 km |
Weight
US | Metric | |
---|---|---|
Operating Weight with Cab | 8983 Ibs | 4894 kg |
Operating Weight with Canopy | 8565 lbs | 3885 kg |
Dimensions
US | Metric | |
---|---|---|
Overall Height with Canopy | 99.0 in. | 251 cm |
Overall Height with Cab | 98.5 in. | 250 cm |
Overall Width Without Bucket | 62.2 in. | 158.0 cm |
Overall Length | 200 in. | 507 cm |
Ground Clearance | 12.0 in. | 30 cm |
Crawler Dimensions
US | Metric | |
---|---|---|
Crawler Overall Length | 83 in. | 211 cm |
Crawler Overall Width | 68.5 in. | 174 cm |
Crawler Shoe Width | 14 in. | 35 cm |
Crawler Base | 65 in. | 165 cm |
Takeuchi Tb240 Price
Model | Hours | Price |
---|---|---|
2014 Takeuchi Tb240 | 2500 | $33,000 |
2015 Takeuchi Tb240 | 1000 | $39,000 |
2016 Takeuchi Tb240 | 1500 | $35,000 |
2017 Takeuchi Tb240 | 1000 | $39,000 |
2018 Takeuchi Tb240 | 800 | $40,000 |
2019 Takeuchi Tb240 | 500 | $42,500 |
2020 Takeuchi Tb240 | 300 | $58,000 |
2021 Takeuchi Tb240 | 50 | $63,000 |
2022 Takeuchi Tb240 | New | $68,000 |
I’m not a seller, I’m just doing price research for you. Takeuchi tb240 prices were reviewed in January 2022. Prices may vary.
Takeuchi TB240 Jobsite crane delivers visibility, versatility, superior ergonomics, and unmatched speed and power. Takeuchi TB240's simple design, uncomplicated hydraulics, and rugged construction make it an ideal excavator for entry-level operators as well as veteran contractors. Designed to deliver outstanding performance with versatility and comfort, the Takeuchi TB240 is ideal for medium applications.Takeuchi Tb240 Review
Performance
Features
Reliability
Drive
Price
These tables have been written to reflect the features of the 124000003 series. There are some differences with the 124100002 series.
The information presented here will help you decide if this product is the best fit for your situation. Though we do our best to provide all the information you need, things can always change. So be sure to do your own research before purchasing a vehicle, because the information in this review may become outdated over time. If you would like exact details, please contact the vendor directly. If you need Takeuchi Tb240 manual, please specify by commenting.
