Kubota bx2380 specs Kubota’s proven 3-cylinder diesel engine, a fuel-efficient choice that provides plenty of power to haul, climb, and pull your way through even the toughest tasks. The Bx2380 Kubota is versatile and powerful enough to handle almost any task around the house or farm. The Kubota tractor bx2380 smaller size allows it to easily maneuver around tight spaces and get in and out of tight spots. This is the tractor for you if you want to get more done faster than you ever imagined possible!
Kubota Bx2380 Specs
| Brand | Kubota |
| Model | Bx2380 |
| Type | Compact tractor |
| Series | Bx80 series |
| Years Made | 2017-2021 |
Engine
The Kubota D902 is a small, clean diesel engine that consumes less fuel and emits less greenhouse gas. It is simple to use and maintain, making it ideal for high-performance applications.
| Brand | Kubota |
| Model | D902 |
| Type | Diesel water Cooled |
| No. of Cylinders | 3 |
| Combustion System | Indirect Injection |
| Intake System | Naturally Aspirated |
| Rated Power | 3600 RPM |
| US | Metric | |
|---|---|---|
| Displacement | 54.8 cu in. | 898 cc |
| Bore and Stroke | 2.8 x 2.9 in. | 7.2 x 7.4 cm |
| Gross Power @ 3200 RPM | 21.6 HP | 16.1 kW |
| Net Power @ 3200 RPM | 17.7 HP | 13.2 kW |
| Maximum Output @ 3600 RPM | 24.8 HP | 18.5 kW |
| Maximum Torque @ 3600 RPM | 41.4 Ib-ft | 56.1 N-m |
Engine Dimensions
| US | Metric | |
|---|---|---|
| Length | 17.1 in. | 43.4 cm |
| Width | 15.8 in. | 40.1 cm |
| Height | 21.4 in. | 54.4 cm |
Engine Weight
| US | Metric | |
|---|---|---|
| Dry Weight | 159 Ibs | 72 Kg |
Transmission
| Type | HST, high-low gear shift (hydrostatic) |
| Gears | 2 forward and reverse |
| Drive Method | 4WD |
| Brakes | Wet |
Travel Speed
| Gear | US | Metric |
|---|---|---|
| F1 | 4.2 mph | 6.75 km |
| F2 | 8.4 mph | 13.5 km |
| R1 | 4.2 mph | 6.75 km |
| R2 | 8.4 mph | 13.5 km |
Dimensions
| US | Metric | |
|---|---|---|
| Wheelbase | 55.1 in. | 140 cm |
| Length (with 3-point hitch) | 95.5 in. | 242.5 cm |
| Height with ROPS | 83.1 in. | 211 cm |
| Width | 45.1 in. | 114.5 cm |
| Ground Clearance | 8.4 in. | 21.4 cm |
| Tread Front | 36.6 in. | 93.0 cm |
| Tread Rear | 32.2 in. | 82.0 cm |
Tire Size
| Standard Tires Front | 18×8.5-10 |
| Standard Tires Rear | 26×12-12 |
| Lawn/turf Tront | 18×8.5-10 |
| Lawn/turf Rear | 26×12-12 |
Weight
| US | Metric | |
|---|---|---|
| Tractor Weight | 1336 Ibs | 606 kg |
Kubota Bx2380 Attachments
Kubota LA344 Loader
The Kubota LA344 Loader has the first Swift-Tach front loader quick-attach system in the industry. One simple hydraulic mechanism attaches and detaches the front loader. The loader swings closed with the machine, making attachment and detachment quick, simple, and convenient without ever leaving the tractor seat.
| US | Metric | |
|---|---|---|
| Clearance, Dumped Bucket | 52.1 in. | 132 cm |
| Height to Pin | 71 in. | 180 cm |
| Dump Reach | 25.4 in. | 64 cm |
| Dump Angle | 45° | 45° |
| Reach at Ground | 54.8 in. | 139 cm |
| Rollback Angle: | 29° | 29° |
| Breakout Force at 500mm | 978 lbs | 443 kg |
| Lift to Full Height at Pin: | 739 lbs | 335 kg |
| Lift to Full Height at 500mm | 509 lbs | 230 kg |
Kubota RCK60B-23BX Mid-Mount Mower
The RCK60B-23BX from Kubota allows you to use a compact tractor for more than just lawn care. This innovative midsole mower deck easily overcomes curbs, hoses, and other obstacles without leaving yard waste behind. In addition, it moves debris where it needs to go, making cleanup quick and simple.
| Type | Side discharge |
| Number of Blades | 3 |
| Mounting Method | Self-balance |
| US | Metric | |
|---|---|---|
| Cutting Width | 60 inches | 152 cm |
| Weight | 250 lbs | 113 kg |
| Cut Height | 1 to 4 inch | 2 to 10 cm |
Kubota Bx2380 Review
Performance
Features
Reliability
Drive
Attachments
The Kubota BX2380 tractor is designed to be light and agile so you can handle your tasks quickly and efficiently. The Kubota BX Series tractors offer a variety of features, such as an independent rear PTO, cruise control, and an integrated cab that is designed to be comfortable for hours on end. If you are looking for the more powerful model, I recommend the bx2680, if you want the bigger one, I recommend you to check the newest model of the BX series, the bx23s.
The information presented here will help you decide if this product is the best fit for your situation. Though we do our best to provide all the information you need, things can always change. So be sure to do your own research before purchasing a vehicle, because the information in this review may become outdated over time. If you would like exact details, please contact the vendor directly. If you need Kubota Bx2380 manual, please specify by commenting.
