Kubota B2650 Tractor can be used for most farm jobs and the attachments come in handy when managing several fields or having multiple properties to look after. Enjoy greater freedom with the B2650 Kubota! We help you make an informed decision about your Kubota B2650. We bring to you the range of specs and reviews that will help you decide whether it’s right for you. This tractor has a wide range of options, including mounting points for all possible attachments, allowing users to tailor this model to their specific needs. Built to meet the needs of any land user, the Kubota B2650 tractor is ready for hard work, with or without an implement. Powered by a Kubota diesel engine and built for durability, you’ll be able to tackle any job, big or small.
The Kubota B2650 tractor can handle all of your chores, whether they are cattle, corn, vegetables, or hay. The powerful 26 HP Kubota diesel engine and new crawler pump provide dependable performance. The B2650 is a strong option for any job site and fuels your success thanks to its innovative specs.
Never miss another job. The new Kubota B2650 Tractor’s high-torque engine and industry-leading Power Curve System deliver the performance you need regardless of terrain or conditions. Kubota b2650 is the most efficient in its class and is best suited for performing medium to light tasks of small to medium-sized farms such as clearing of debris and felling trees. Kubota b2650 is a powerful machine that has 26 horsepower. It uses Kubota diesel engines. This is perhaps the best garden tractor for large gardens.
There’s no surprise that the Kubota b2650 is so popular. You’ll love its power, superb performance, comfort, and reliability. Kubota B2650 tractor was developed by the Kubota family who has been involved with farming for over 100 years. The Kubota B2650 tractor is a powerful diesel machine, its 26HP diesel engine, coupled with its easy-to-use versatility and dependability make it an able workhorse for all your jobs that matter most. Whether you’re mowing, landscaping, or doing light utility work, the new B2650 Kubota Tractor is the best choice for durability, versatility, and comfort.
Kubota B2650 Specs
Brand | Kubota |
Model | B2650HSD |
Series | B50 series |
Type | Compact utility tractor |
Years Made | 2013-2021 |
Engine
Kubota has a wide assortment of engines that have been built with high-quality materials to be made for sturdier power output and enhanced torque. Taking into account, the environment and its protection, the Kubota B50 engines have been specifically planned using a cooling system that is more reliable, cleaner and generates greater power. The Kubota B2650 extends this variety to include tractor power.
Engine Features
Brand | Kubota |
Model | D1305-E4-D26-R |
Type | Diesel liquid-cooled |
No. of Cylinders | 3 |
Rated Power | 2500 RPM |
Low Idling Revolution | 1100 RPM |
Battery | 12V, RC: 80min, CCA: 430A |
Lubrication | Forced lubrication |
Cooling System | Pressurized radiator |
Radiator Fan | Radial airflow |
Engine Specs
Specs | US | Metric |
---|---|---|
Horsepower | 25 HP | 19 kW |
PTO Power | 19.5 HP | 14.5 kW |
Bore and Stroke | 3.1×3.5 inches | 78×88 mm |
Displacement | 77 cu in. | 1261 cc |
Gross Power | 24.8 HP | 18.5 kW |
Max. Torque | 62 ft-Ib | 84 Nm |
Traveling System
The Kubota B2650 tractor has a three-range transmission that allows you to control your speed with precision. The left brake pedal engages the hydraulic retarder so you can adjust down speeds quickly, especially in tricky fields.
Steering | Hydrostatic type power steering |
Transmission | Main hydrostatic transmission |
Gear | 3 range gear shift (3 forward, 3 reverse) |
Brake | Wet disk type |
Oil Capacity | 16 quarts – 15.1 L |
Travel Speed (12.4 – 16 Farm)
Metric | US | |
---|---|---|
F1 | 5.7 km | 3.6 mph |
F2 | 8.5 km | 5.3 mph |
F3 | 18.0 km | 11.2 mph |
R1 | 4.3 km | 2.7 mph |
R2 | 6.4 km | 3.9 mph |
R3 | 13.5 km | 8.4 mph |
Travel Speed (13.6 – 16 Turf)
Metric | US | |
---|---|---|
F1 | 6.0 km | 3.7 mph |
F2 | 8.9 km | 5.5 mph |
F3 | 18.9 km | 11.7 mph |
R1 | 4.5 km | 2.8 mph |
R2 | 6.7 km | 4.1 mph |
R3 | 15.0 km | 8.8 mph |
Dimensions
Overall Length | 101.2 in. | 257 cm |
Overall Width | 53.7 in. | 136.5 cm |
Overall Height | 88.4 in. | 224.5 cm |
Wheelbase | 65.6 in. | 166.6 cm |
Min. Ground Clearance | 14.6 in. | 370 cm |
Tread Front | 36.8 in. | 93.5 cm |
Tread Rear | 41.3 in. | 105 cm |
Weight
US | Metric | |
---|---|---|
Weight | 1786 Ibs | 810 kg |
Tire Size
Standard tires Front | 7-12 |
Standard tires Rear | 12.4-16 |
Lawn/turf Front | 24×8.50-14 |
Lawn/turf Rear | 13.6-16 |
Industrial Front | 23×8.50-14 |
Industrial Rear | 12.4-16 |
Attachments
The Kubota B2650 is a versatile tractor with multiple implements and attachments, so it can be used to perform a variety of tasks, from digging and loosening the soil to pulling and towing implements.
LA534A Front Loader
The Kubota LA series of front loaders offers a variety of lift levels and options, making them ideal for landscaping and light utility work. The LA534A front loader offers a big lifting capacity, perfect for landscaping or light utility work.
LA534A Front Loader Specs
Maximum lift height (to bucket pivot pin) | 84.6 in. | 215 cm |
Clearance with attachment dump | 67.4 in. | 171.2 cm |
Maximum dump angle | 38.1° | 38.1° |
Max. rollback angle | 28.6° | 28.6° |
Lift capacity (pivot pin) | 1146 Ibs | 520 kg |
Lift capacity (19.7in. forward) | 827 Ibs | 375 kg |
Breakout force (pivot pin) | 2321 Ibs | 1053 kg |
Breakout force (19.7in. forward) | 1691 Ibs | 767 kg |
Mid Mount Mower
These mid-mount mowers feature cutting height adjustments from 1.5 to 4 inches in 0.5-inch increments, and they’re ultra-sturdy and ultra-versatile.
Mid Mount Mower RCK60-30BA
This is a 3-blade, RH discharge mid-mount mower deck that fits Kubota B2650 and B3350 tractors.
Mid Mount Mower RCK60-30BA Features
Type | Side discharge |
Serial | 34395 |
Number of blades | 3 |
Mounting method | Floating |
Adjustment of cutting height | Guage wheel |
Mid Mount Mower RCK60-30BA Specs
Specs | US | Metric |
---|---|---|
Cutting width | 60.0 in. | 152.4 cm |
Cutting height | 1 to 4 in. | 3.6 to 10.2 cm |
Weight | 374 Ibs | 170 kg |
Mid Mount Mower RC72-30B
The RC72-30B mower deck is designed to be used on the B2650 and B3350 tractors. This deck and other Kubota implements are built for efficiency and productivity.
Mid Mount Mower RC72-30B Features
Type | Side discharge |
Number of blades | 3 |
Mounting method | Floating |
Adjustment of cutting height | Guage wheel |
Mid Mount Mower RC72-30B Specs
Specs | US | Metric |
---|---|---|
Cutting width | 72.0 in. | 182.6 cm |
Cutting height | 1 to 4 in. | 3.6 to 10.2 cm |
Weight | 463 Ibs | 210 kg |
Blade length | 24.6 in. | 62.5 cm |
Blade Spindle Speed | 2400 RPM | 2400 RPM |
Overall Width | 88.5 in. | 224.7 cm |
Backhoe
The Kubota BH77 Backhoe is performance-matched with the B50 Tractors to deliver more power and greater digging capacity.
BH77 Backhoe Features
Model | BH77 |
Bucket Rotation | 180.0º |
Angle of Departure Per SAE J1234 | 17.5º |
Leveling Angle | 10.2º |
Swing Arm | 180.0º |
BH77 Backhoe Specs
Specs | US | Metric |
---|---|---|
Transport Height | 80.7 in. | 205.1 cm |
Stabilizer Spread – Transport | 51.8 in. | 131.5 cm |
Ground Clearance | 12.6 in. | 31.9 cm |
Operating Height Fully Raised | 119.2 in. | 302.9 cm |
Reach from Swing Pivot | 124.6 in. | 316.5 cm |
Swing Pivot to Rear Axle Center Line | 38.4 in. | 97.6 cm |
Kubota B2650 Price
Kubota B2650 costs around $30,000. The price of used Kubota b2650 for sale is $20,000 starting price.
Kubota B2650 Cab
Kubota B2650’s sleek cab design allows comfort that no other tractor can offer, from the warm modern cabin to the roomy front seats. Shortly after getting into the driver’s seat, you’ll feel like you’re in control of more than just a powerful piece of machinery. Kubota tractors have long been known for creating powerful machines that are a joy to both use and look at. As the first in its class to have an integrated cab, the B2650 Kubota takes comfort to the next level.
Kubota B2650 tractor provides a quieter, more comfortable work environment than many other compact tractors and is ideal for areas where noise levels are regulated.
Kubota B2650 Reviews
You will find our Kubota b2650 rating below, but we wanted to include reviews from b2650 users. Here are some b2650 Kubota users’ comments below.
- I had been looking around at different tractors for a while, and when I saw the Kubota B2650, I knew right away it was the one for me. The seat is roomy and comfortable, but the best part is that it goes through pretty much anything. The air conditioning is nice on these long hauls from one job to another!
- This powerful middle-size tractor has an extended, heavy duty reach arm that can do all sorts of jobs. It’s great for clearing small fields or gardens, leveling the ground underneath fruit trees, or moving compost.
- B2650 is a compact, very reliable machine that works really well on small farms. If you’re looking for a tractor that’s easy to wheel around, the B2650 will be a very good choice.
The Kubota B2650 tractor is made for comfort and durability. The new operator's compartment and cabin design give you a wide, open space. The new headlight and turn signals provide better visibility and safety, while the new steering wheel and pedal arrangement allow greater comfort and control.Kubota B2650 Review
Performance
Features
Reliability
Drive
Attachments
The information presented here will help you decide if this product is the best fit for your situation. Though we do our best to provide all the information you need, things can always change. So be sure to do your own research before purchasing a vehicle, because the information in this review may become outdated over time. If you would like exact details, please contact the vendor directly. If you need Kubota B2650 manual, please specify by commenting.
