Bobcat 442 excavator is equipped with an axial-piston pump, which can adjust the flow of fluid based on how much force is applied to it. It also has a load-independent flow division system, which allows for independent control of all machine movements. The right-hand corner of the 442 Bobcat is designed so that the bucket can swing all the way to the side. This makes it simple to load trucks while moving alongside other objects. With a height to bucket pin of 5.2 m, the 442 can load trucks with high sides up to 4.2 m high.
The Bobcat 442 has a spacious cab that keeps the operator cool and dry. It also has a suspension seat that can be adjusted for added comfort. A safety (anti-drop) boom valve is included as standard equipment, as is a load moment device that alerts operators when the excavator’s stability limit is reached.
Bobcat 442 Specs
The specs for Bobcat e26 2008 model and up are listed below. The specifications of an E26 Bobcat are generally the same, but the features and emissions of the engines differ depending on the year of manufacture.
Manufacturer | Bobcat |
Model | 442 |
Type | Mini excavator |
Years Made | 2002-2010 |
Engine
Brand | Deutz |
Model | TD 2011 L04W |
Type | Diesel four-stroke |
No. Of Cylinders | 4 |
Emissions | Tier 3 |
Charging | Exhaust gas turbocharger |
Combustion | Direct |
Injection Pump | Pump-pipe-nozzle |
Order Firing | 1-3-4-2 |
Rated Speed | 2200 RPM |
Rated Torque | 1600 RPM |
US | Metric | |
---|---|---|
Horsepower | 73 HP | 54 kW |
Torque Power | 199 ft-lbs | 270 Nm |
Displacement | 190 cu in. | 3.11 L |
Bore | 3.8 in. | 9.6 cm |
Stroke | 4.9 in. | 12.5 cm |
Capacity
US | Metric | |
---|---|---|
Fuel Tank | 34.4 gal | 130 L |
Hydraulic System | 37.0 gal | 140 L |
Hydraulic Reservoir | 29.1 gal | 110 L |
Oil Capacity | 2.6 gal | 10.0 L |
Performance
US | Metric | |
---|---|---|
Lift Capacity | 5190 lbs | 2354 kg |
Lift Radius | 118 in. | 300 cm |
Arm Breakout Force | 9577 lbf | 42600 N |
Bucket Breakout Force | 11960 lbf | 53200 N |
Max. Dump Height | 165 in. | 420 cm |
Max. Digging Depth | 165 in. | 420 cm |
Max. Reach at Ground Level | 201 in. | 730 cm |
Slew System
Boom Swing Right | 65° |
Boom Swing Left | 63° |
Slew Rate | 10.0 RPM |
Travel Speed
US | Metric | |
---|---|---|
Low Speed | 1.7 mph | 2.7 km |
Max. Speed | 3.2 mph | 5.1 km |
Hydraulic System
US | Metric | |
---|---|---|
Pump Capacity | 41.2 Gpm | 156 Lpm |
Gear Capacity | 18.0 Gpm | 68.0 Lpm |
Auxiliary Flow | 26.4 Gpm | 100 Lpm |
Dimensions
US | Metric | |
---|---|---|
Length | 237 in. | 603 cm |
Width | 92 in. | 234 cm |
Height | 107 in. | 272 cm |
Weight
US | Metric | |
---|---|---|
Operating Weight | 17100 lbs | 7751 kg |
I have a bobcat 442, which has a lot of power and I adore it. The one thing I don't like about digging is that you can't get too near to walls or anything else since the bucket will strike and ruin your work, but there's always a way around it. I've used it to dig large holes, move large rocks, and do a variety of other tasks. It's a good reliable machine and there's nothing wrong with buying one new.Bobcat 442 Review
Performance
Features
Reliability
Drive
Price
The information presented here will help you decide if this product is the best fit for your situation. Though we do our best to provide all the information you need, things can always change. So be sure to do your own research before purchasing a vehicle, because the information in this review may become outdated over time. If you would like exact details, please contact the vendor directly. If you need Bobcat 442 manual, please specify by commenting.
