Kubota U17 mini excavator is versatile, lightweight, and easy to operate. U17 Kubota excavator delivers the power of a full-size excavator in a compact design. With a low center of gravity and easy-to-operate controls, it maneuvers in tight spots so you spend more time doing and less time moving your machine. U17 Kubota excavator will make short work of any job you throw at it.
Kubota U17 Specs
| Brand | Kubota |
| Model | U17 |
| Series | U series |
| Type | Mini excavator |
| Years Made | 2008-2022 |
Engine Specs
| Brand | Kubota |
| Engine Model No | Kubota D902-E4 |
| Type | Diesel V 4 cycle |
| No. of Cylinders | 3 |
| Emissions | Tier 4 |
| Combustion | Spherical type (E-TVCS) |
| Fuel Injection Pump | Bosch MD type mini pump |
| Injection Nozzle | Bosch throttle type |
| Injection type | Indirect |
| Firing Order | 1-2-3 |
| Compression Ratio | 24:1 |
| Rotation | Counter-clockwise |
| Lubricating System | Forced lubrication by trochoid pump |
| Lubricating Filter | Cartridge type |
| Oil Pressure Indicating | Electrical type switch |
| Starter | Electric Starting |
| Fuel | Diesel Fuel No.2-D |
| Lubricant | Above CF |
| Rated Speed | 2300 RPM |
| Max. Bare Speed | 2650 RPM |
| Low Idle Speed | 1350 RPM |
| Starter | 12 V cell starter |
| US | Metric | |
|---|---|---|
| Horsepower | 17.0 HP | 12.7 kW |
| Displacement | 54.8 cu in. | 898 cc |
| Bore and Stroke | 2.8×2.9 in. | 7.2×7.4cm |
| Fuel Tank Capacity | 5.0 gal | 19 L |
| Oil Capacity | 1.0 gal | 3.7 L |
| Coolant Capacity | 0.7 gal | 2.6 L |
| Injection Timing | 0.33 rad | 19° |
| Injection Pressure | 1991 psi | 13.73 MPa |
| Starter | 1.6 HP | 1.2 kW |
Engine Dimensions
| US | Metric | |
|---|---|---|
| Length | 35.2 in. | 89.4 cm |
| Width | 21.6 in. | 54.9 cm |
| Height | 29.8 in. | 75.7 cm |
Engine Weight
| US | Metric | |
|---|---|---|
| Dry Weight | 141 lbs | 64 kg |
Performance
| US | Metric | |
|---|---|---|
| Breakout Force Bucket | 3417 lbs | 1550 kg |
| Max. Digging Depth | 91.0 in. | 231.1 cm |
| Max. Dumping Height | 96.0 in. | 243.8 cm |
| Ground Pressure | 3.8 psi | 26.2 KPa |
| Max. Arm Digging Force | 1918 lbs | 870 kg |
| Traction Force | 2899.1 lbs | 1315 kg |
Lifting Capacity
Lifting Capacity Over Front Blade Down
Lifting Capacity Over Front Blade Up
Lifting Capacity Over Side Track Width 48 in.
Swing System
| Right | 58° |
| Left | 68° |
| Swing Speed – Right | 3.7 sec. |
| Swing Speed – Left | 4.6 sec. |
| Slew Speed | 9.1 RPM |
| Swing Bracket | 62 lbs (28 kg) |
Travel Speed
| US | Metric | |
|---|---|---|
| Low Speed | 1.4 mph | 2.1 km |
| High Speed | 2.6 mph | 4.1 km |
Hydraulic System
| US | Metric | |
|---|---|---|
| Total Hydraulic Flow | 4.6 GPM | 17.3 Lpm |
| Auxiliary Flow | 7.3 GPM | 27.7 Lpm |
Weight
| US | Metric | |
|---|---|---|
| Operating Weight | 3,814 Ibs | 1,730 kg |
Parts Weight
| lbs | Kg | |
|---|---|---|
| Machine weight | 3704 | 1680 |
| Body weight | 3527 | 1340 |
| Maximum breaker weight | 198 | 90 |
| Backhoe overall | 390 | 177 |
| Upper swivel structure | 1799 | 816 |
| Lower travel structure | 1272 | 577 |
| Swivel frame | 331 | 150 |
| Swing bracket | 62 | 28 |
| Boom | 148 | 67 |
| Arm | 66 | 30 |
| Bucket | 88 | 40 |
| Dozer | 148 | 67 |
| Counterweight | 452 | 205 |
| Iron crawler | 196 | 89 |
| Rubber crawler | 124 | 56 |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 90.6 in. | 230.0 cm |
| Width | 48.8 in. | 124.0 cm |
| Lenght | 102.4 in. | 357.0 cm |
| Ground Clearance | 5.9 in. | 15.0 cm |
Undercarrige
| Under Carriage Shoe Width | 9.1 in. | 23.0 cm |
| Crawler total length | 62.5 in. | 158.7 cm |
| Crawler total width | 48.8 in. | 124.0 cm |
| Lug height | 0.9 in. | 2.7 cm |
| Iron core pitch | 3.8 in. | 9.65 cm |
| Circumference | 132.3 in | 336 cm |
| Number of steel cords | 1.89 in | 4.8 cm |
| Steel cords lap length | 10.2 in. | 26 cm |
| Steel cords strength | 882 lbf | 3.92 KN |
| Thickness of crawler main part | 0.9 in. | 2.3 cm |
| Ditto joint parts | 1.0 in. | 2.7 cm |
Kubota U17 Price
| Model | Hours | Price |
|---|---|---|
| 2008 Kubota U17 | 4000 | $11,000 |
| 2008 Kubota U17 | 3500 | $12,500 |
| 2010 Kubota U17 | 3500 | $13,000 |
| 2011 Kubota U17 | 3250 | $14,500 |
| 2012 Kubota U17 | 3100 | $16,000 |
| 2013 Kubota U17 | 2800 | $17,500 |
| 2014 Kubota U17 | 2000 | $19,000 |
| 2015 Kubota U17 | 1800 | $22,000 |
| 2016 Kubota U17 | 1600 | $24,000 |
| 2017 Kubota U17 | 1500 | $27,000 |
| 2018 Kubota U17 | 1500 | $28,000 |
| 2019 Kubota U17 | 1200 | $29,000 |
| 2020 Kubota U17 | 250 | $30,000 |
| 2021 Kubota U17 | 50 | $37,000 |
| 2022 Kubota U17 | New | $41,000 |
We are not sellers. We’ve done the research to give you an idea about the Kubota u17 price. This research was conducted in February 2022. Kubota u17 price search may vary by region and time.
The Kubota U17 is the right choice for commercial contractors, sod farms and large acreage owners who need a versatile and productive machine to tackle tough jobs at competitive prices.Kubota U17 Review
Performance
Features
Reliability
Drive
Price
The information presented here will help you decide if this product is the best fit for your situation. Though we do our best to provide all the information you need, things can always change. So be sure to do your own research before purchasing a vehicle, because the information in this review may become outdated over time. If you would like exact details, please contact the vendor directly. If you need Kubota U17 manual, please specify by commenting.
