Known as one of the best-selling utility tractors in American history, the Ford 6610 from 1982 to 1993 offered superior traction capabilities at a competitive price. It’s perfect for a small farm or homestead. Designed for use with a range of implements and attachments, the 6610 Ford tractor presents a durable and reliable option for farmers everywhere. The 6610 from Ford is a timeless classic. It’s the perfect vehicle for farmers, ranchers, and commercial operators alike.
Ford 6610 tractors improve on some of their predecessor’s shortcomings. A full transmission option, simplicity in operation, and maintenance set the 6610 apart from other models on the market. With the full-power shift transmission, four-speed power shuttle transmission, and quick-hitch system, you don’t have to worry about getting your 6610 through any type of terrain. You can also attach a variety of implements to complete your job quickly and efficiently.
Built for ranchers and farmers, the Ford 6610 tractor doesn’t skip a beat. With the puncture-proof tires and additional traction, it is ready to take on any job you give it, whether it be moving cattle or cutting hay. Prepare yourself for bigger projects. The 6610 is designed with features that make it easy to handle bigger difficulties. A powerful engine, rear dual wheels, improved equipment, and improved safety are just some of the vehicular surprises that await you when you get behind the wheel of this work beast.
6610 Ford Tractor Specs
| Brand | Ford |
| Model | 6610 |
| Type | Utility tractor |
| Years Made | 1982-1993 |
Engine
| Manufacturer | Ford |
| Model | E626333 |
| Type | Diesel, liquid-cooled |
| No. of Cylinders | 4 |
| Combustion | Direct injection |
| Rated Speed | 2100 RPM |
| Starter | 12V Negative |
| Generator | Lucas 18 Acr |
| Battery | Ford lead acid |
| Compression Ratio | 16.3:1 |
| Specs | US | Metric |
|---|---|---|
| Gross Power | 82.5 HP | 61.5 kW |
| Net Power | 77.0 kW | 57.5 kW |
| Displacement | 14.52 cu in. | 4.39 L |
| Bore and Stroke | 4.4 inx4.4 in. | 11.18×11.18 cm |
| Max. Torque | 219 Ib-ft | 297 Nm |
| Coolant Capacity | 18.0 qts | 17.0 L |
| Oil Capacity | 9.0 qts | 8.5 L |
| Starter Motor Power | 2.4 HP | 1.8 kW |
Transmission
| Transmission | Synchromesh |
| Gear | 12 range (8 forward and 4 reverse) |
| Clutch Brand | Borg and Beck |
| Clutch Type | Dry, single plate |
| Transmission Oil Capacity | 56.8 L (60 L) |
| Oil Change Period | 1200 hours |
| Oil Filter Change Period | 300 hours |
Travel Speed
| Gear | US (mph) | Metric (km) |
|---|---|---|
| F1 (Low) | 1.7 | 2.7 |
| F2 (Low) | 3.9 | 2.5 |
| F3 (Low) | 3.6 | 5.8 |
| F4 (Low) | 5.2 | 8.4 |
| F1 (High) | 6.0 | 9.6 |
| F2 (High) | 8.6 | 13.9 |
| F3 (High) | 12.7 | 20.4 |
| F4 (High) | 18.4 | 29.6 |
| R1 (High) | 2.2 | 3.5 |
| R2 (High) | 3.2 | 5.1 |
| R3 (High) | 4.6 | 7.5 |
| R4 (High) | 6.7 | 10.8 |
Dimensions
| Dimension | US | Metric |
|---|---|---|
| Wheelbase | 88 in. | 223 cm |
| Lenght | 148 in. | 378 cm |
| Width | 69 in. | 175 cm |
| Clearance front axle | 18 in. | 45.5 cm |
| Height to ROPS | 96 in. | 243 cm |
| Height to Cab | 107 in. | 270 cm |
Weight
| Weight | US | Metric |
|---|---|---|
| Shipping Weight | 5700 Ibs | 2585 kg |
| Operating Weight | 7000 Ibs | 3175 kg |
Tires
- Ag Front 2WD: 7.50-16
- Ag Front 4WD: 11.2-24
- Ag Rear: 16.9-30
- Ag Front 2WD: 7.50-18
- Ag Front 2WD: 10.00-16
- Ag Front 4WD: 12.4-24
- Ag Front 4WD: 13.6-24
- Ag Front 4WD: 14.9-24
- Ag Rear: 18.4-30/16.9-34/18.4-34/15.5-38/16.9-38
Attachments
Ford 777B Loader
- Loader Seight: 1390 lbs – 630 kg
- Height (to pin): 124 in. – 314 cm
- Clearance, Dumped Bucket: 100 in. – 254 cm
- Dump Reach: 44.9 in. – 114 cm
- Dump Angle: 47°
- Reach at Ground: 76 in. – 193 cm
- Rollback Angle: 14°
- Breakout Force (lift): 4550 lbs – 2063 kg
- Lift to Full Height (at pin): 2500 lbs – 1134 kg
- Bucket Width: 48 in. – 121 cm/60 inches 152 cm/72 inches 182 cm
Ford 777D Loader
- Loader Seight: 1415 lbs – 641 kg
- Height (to pin): 125 in. – 312 cm
- Clearance, Dumped Bucket: 100 in. – 254 cm
- Dump Reach: 34 in. – 86 cm
- Dump Angle: 47°
- Reach at Ground: 68 in. – 172 cm
- Rollback Angle: 14°
- Breakout Force (lift): 5500 lbs – 2500 kg
- Lift to Full Height (at pin): 2900 lbs – 1315 kg
- Bucket Width: 48 in. – 121 cm/60 inches 152 cm/72 inches 182 cm
Ford 777F Loader
- Loader Seight: 1636 lbs – 742 kg
- Height (to pin): 121 in. – 307 cm
- Clearance, Dumped Bucket: 98 in. – 248 cm
- Dump Reach: 40 in. – 102 cm
- Dump Angle: 40°
- Reach at Ground: 74 in. – 187 cm
- Rollback Angle: 13°
- Breakout Force (lift): 4800 lbs – 2177 kg
- Lift to Full Height (at pin): 2900 lbs – 1315 kg
- Bucket Width: 48 in. – 121 cm/60 inches 152 cm/72 inches 182 cm
The information presented here will help you decide if this product is the best fit for your situation. Though we do our best to provide all the information you need, things can always change. So be sure to do your own research before purchasing a vehicle, because the information in this review may become outdated over time. If you would like exact details, please contact the vendor directly. If you need Ford 6610 manual, please specify by commenting.
