John Deere 1023e Specs
Specifications for the John Deere 1023E are given below.
Brand | John Deere |
Model | 1023e |
Type | Sub Compact Utility tractor |
Years Made | 2016-2021 |
Engine Specs
Brand | Yanmar |
Model | 3TNM74F-NCJT |
Type | Diesel |
No. of Cylinders | 3 |
Rated Speed | 3200 RPM |
Combustion | Indirect Injection |
Aspiration | Natural |
Emission | EU Stage V, EPA Tier IV Final, Lower Regulated Countries |
Compression Ratio | 23.5:1 |
US | Metric | |
---|---|---|
Gross Power | 21.5 HP | 16 kW |
PTO Power | 14.9 HP | 11.1 kW |
Displacement | 60.6 cu in. | 993 cc |
Bore and Stroke | 2.91 x 3.03 in. | 7.4×7.7 cm |
Engine Torque | 35.2 lb-ft | 47.7 Nm |
Fuel Tank Capacity | 6.3 gal | 24 L |
Transmission
Transmission | Hydrostatic |
Gear | 2-range (forward/reverse) |
Travel Speed
Gear | US | Metric |
---|---|---|
F1 | 4.15 | 6.7 |
F2 | 9.15 | 14.5 |
R1 | 4.15 | 6.7 |
R2 | 9.15 | 14.5 |
Lift Capacity
US | Metric | |
---|---|---|
Lift capacity (24 in. Behind Link Arms) | 758 lb | 344 kg |
Dimensions
Dimension | US | Metric |
---|---|---|
Wheelbase | 57 in. | 145 cm |
Height to Hood | 42 in. | 106 cm |
Height to ROPS | 86.2 in | 218 cm |
Front Axle Clearance | 7.7 in. | 19.5 cm |
Turning Radius (without brakes) | 98.4 in. | 251 cm |
Front Tread Range | 36.7 in. | 93 cm |
Rear Tread Spacing | 35.2 in. | 89.5 cm |
Tires
Front Tires (Industrial and Turf) | 18×8.5-10 |
Rear Tires (Industrial and Turf) | 26×12-12 |
Weights
Weight | US | Metric |
---|---|---|
Shipping Weight | 1450 Ibs | 660 kg |
Axle Front Capacity | 1350 Ibs | 612 kg |
Axle Rear Capacity | 1575 lbs | 715 kg |
John Deere 1023E is a tractor that makes it easy to tackle any job. Whether you want to mow some grass or add some color to your landscape, this tractor will make the whole process stress-free. Everyone needs a good tractor. And you’re in luck because the 1023E John Deere is an excellent choice for all your landscaping tasks.
With a wide range of attachments, the JD1023e can do almost anything. From edging and mowing to moving piles of dirt with the bucket and digging trenches with its backhoe, this tractor can keep any operation moving smoothly and efficiently. Deere 1023e offers a wide variety of attachments to help make your job easier and more productive.
With a Yanmar 3TNM72 diesel engine, the 1023e John Deere tractor is highly efficient and powerful enough for even your heaviest jobs. The liquid cooling system in this John Deere engine can remove heat from the engine up to 30 times more effectively than air. It also helps protect the environment by cutting down on emissions. The liquid cooling system keeps the engine cool so it operates at peak power. Designed to provide efficient traction across a wide variety of terrain, the John Deere 1023E provides all the power you need.
The John Deere 1023E is the perfect tractor for both large and small lawns. Its wide mower deck makes cutting grass more efficient, while the mid-mounted 54” or 60” deck adds to its versatility so you can take care of commercial or residential properties alike. Lightweight and garden-ready, the 1023E John Deere is great for small lawns, grass cutting, or farming.
John Deere 1023e Reviews
The 1023E by John Deere is a comfort-sized lawn and garden tractor that’s big inside and small outside. It offers an open and comfortable operator environment and user controls and has heavy-duty features you need every day like a 40 amp alternator.
John Deere 1023E is a well-built, workhorse to fit your needs. This small tractor is the ideal choice for the homeowner who wants to maintain their property but doesn’t need anything complicated. It uses hydrostatic transmission so that you have control over the speed at which you work. This ensures that you’re able to maintain your property in a simple fashion, with enough power for almost any task.
The JD 1023E is the ultimate in mid-mounted mower decks. This machine works hard to bring you a beautiful lawn. And it’s so easy to use!
Here are some John Deere 1023e reviews on the internet.
- I’ve owned my 1023E for two years now and haven’t had any problems with it. It’s light enough to put into tight spots, yet has the power to do most jobs the same size tractors would do. I use it for hauling rocks out of my fields, hauling logs out of my woods, and even clearing out some brush.
- If you’re looking for a small tractor that does big jobs, this may be the one. It works great around the house, able to carry whatever you need to finish the day’s chores.
- I have been very pleased with this piece of equipment. It has some challenging power as well as stability for a machine this size. I absolutely recommend the JD 1023E to any person who wants a dependable and powerful little tractor.
John Deere 1023e Price
The John Deere 1023e is the perfect solution when there’s tough work to be done. This model can handle everything from professional landscaping jobs to large gardens for hobbyists. The price for a new (2021) John Deere 1023e can be as low as $13,050.
The 1023E by John Deere is a comfort-sized lawn and garden tractor that’s big inside and small outside. It offers an open and comfortable operator environment and user controls and has heavy-duty features you need every day like a 40 amp alternator. John Deere 1023E is a well-built, workhorse to fit your needs. This small tractor is the ideal choice for the homeowner who wants to maintain their property but doesn’t need anything complicated. It uses hydrostatic transmission so that you have control over the speed at which you work. This ensures that you’re able to maintain your property in a simple fashion, with enough power for almost any task. The JD 1023E is the ultimate in mid-mounted mower decks. This machine works hard to bring you a beautiful lawn. And it's so easy to use!John Deere 1023e Review
Performance
Features
Reliability
Drive
Price
The information presented here will help you decide if this product is the best fit for your situation. Though we do our best to provide all the information you need, things can always change. So be sure to do your own research before purchasing a vehicle, because the information in this review may become outdated over time. If you would like exact details, please contact the vendor directly.
