Kobelco 210 excavator is designed for superior performance. Kobelco machines with outstanding maneuverability and owing to their wide load limit, save on time and money on overhead costs. We’re talking a 210 Kobelco excavator with a wider digging radius, a cabin with improved ventilation and increased visibility, and a repositionable counterweight, all optimized to make work easier.
Kobelco 210 Specs
| Brand | Kobelco |
| Model | SK210LC-8 |
| Series | SK series |
| Type | Excavator |
| Years Made | 2015-2022 |
Engine Specs
| Brand | Hino |
| Engine Model No | J05E |
| Type | Diesel V 4 cycle |
| No. of Cylinders | 4 |
| Emissions | Tier 4 |
| Combustion | Direct injection |
| Injection Type | Common rail |
| Aspiration | Turbocharged |
| Firing Order | 2-3-1-4 |
| Compression Ratio | 17.0:1 |
| Rated Speed | 2000 RPM |
| Torque Speed | 1600 RPM |
| US | Metric | |
|---|---|---|
| Horsepower | 158.2 HP | 118.0 kW |
| Displacement | 312.6 cu in. | 5123 cc |
| Bore and Stroke | 4.4×5.1 in. | 11.2×13.0cm |
| Lubrication Oil Cap | 5.8 in. | 22.0 L |
| Coolant Capacity | 5.8 in. | 22.0 L |
Engine Dimensions
| US | Metric | |
|---|---|---|
| Length | 41.5 in. | 105.3 cm |
| Width | 32.9 in. | 83.6 cm |
| Height | 42.7 in. | 108.5 cm |
Engine Weight
| US | Metric | |
|---|---|---|
| Dry Weight | 1261 lbs | 572 kg |
Performance
| US | Metric | |
|---|---|---|
| Max. Digging Reach | 389.8 in. | 990 cm |
| Max. Digging Depth | 263.8 in. | 670 cm |
| Max. Digging Height | 382.7 in. | 972 cm |
| Max. Dumping Clearance | 272.0 in. | 691 cm |
| Min. Dumping Clearance | 95.7 in. | 243 cm |
| Max. Vertical Wall Digging Depth | 240.2 in. | 610 cm |
| Min. Swing Radius | 139.8 in. | 355 cm |
| Bucket Digging Force | 20.7 psi | 143 KN |
| Arm Crowding Force | 14.8 psi | 102 KN |
| Bucket Capacity | 1.3 yd³ | 1.0 m³ |
| Ground Pressure | 5.7 psi | 39 KPa |
Swing System
| Swing Motor | Axial piston motor |
| Brake | Hydraulic |
| Parking Brake | Hydraulic disc |
| Slew Speed | 12.5 RPM |
| US | Metric | |
|---|---|---|
| Tail Swing Radius | 108.3 in. | 275 cm |
| Min. Front Swing Radius | 139.4 in. | 354 cm |
Travel Speed
| US | Metric | |
|---|---|---|
| Low Speed | 2.2 mph | 3.6 km |
| High Speed | 3.7 mph | 6.0 km |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Capacity (pumps x2) | 58.1 GPM | 220 LPM |
| Pump Capacity (gear x1) | 5.3 GPM | 20 LPM |
Weight
| US | Metric | |
|---|---|---|
| Operating Weight | 47840 lbs | 21,700 kg |
Dimensions
| US | Metric | |
|---|---|---|
| O/A Lenght | 376.4 in. | 956.0 cm |
| O/A Height to Top of Boom | 117.3 in. | 298.0 cm |
| O/A Height to Top of Cabin | 119.3 in. | 303.0 cm |
| O/A Width | 117.7 in. | 299.0 cm |
Undercarrige
| US | Metric | |
|---|---|---|
| Track Gauge | 94.1 in. | 239.0 cm |
| Shoe Width | 27.6 in. | 70.0 cm |
| Ground Clearance | 17.7 in. | 45.0 cm |
I helped dig sewers and basements for my job at Kobelco 210 excavator for five years. They held up good till 7500 hours then were breaking down, and were traded-in. My opinion: with proper maintenance, I could see 10000 hours. Kobelco 210 Review
Performance
Features
Reliability
Drive
Price
The information presented here will help you decide if this product is the best fit for your situation. Though we do our best to provide all the information you need, things can always change. So be sure to do your own research before purchasing a vehicle, because the information in this review may become outdated over time. If you would like exact details, please contact the vendor directly. If you need Kobelco 210 manual, please specify by commenting.
