John Deere 160 Excavator is a powerful machine for any purpose. It is ideal for construction, mining operations, and landscaping design applications. If you want to get the job done, you need a reliable excavator. Easy to use John Deere 160 excavator makes life easier for you and your crew. The new 160 Excavator of Deere is more productive, faster, and economical than its predecessors.
John Deere 160 Excavator Specs
Engine
Electronic filters on John Deere 160 Excavator reduce emissions by burning unwanted particulates. The EPA Stage IV engine runs quietly and efficiently using cooled exhaust gas recirculation (EGR) and low-maintenance high-uptime exhaust filters. The SCR catalysts perform an active role in taking harmful emissions out of the air. It reduces noise, fuel consumption, and operating costs, back-blowing cool cores to keep them clean. High-trash environments and high altitudes are no problem for this cooling system that runs efficiently. The fans blow as needed, which reduces noise and fuel consumption. They run automatically when the reverse is chosen. In addition, the cooling system keeps things from heating up.
Emission Rating | Stage IV / Tier 4 |
Engine Manufacturer | John Deere Power Tech |
Number Of Cylinders | 4 |
Rated speed | 2200 |
Displacement | 4.5 ltr – 275 Inches³ |
Off-Level Capacity | 70% (35 deg.) |
Engine Net Power | 90 kW – 122 Hp |
Number Of Carrier Rollers | 2 |
Number Of Track Rollers | 7 |
Aspiration | Turbocharged, air to air |
Max. Travel Speed | 5.3 km/h – 3.3 mph |
Dimensions
With its low-profile aluminum hood, extra front and side glass, narrow posts at the front of the cab, overhead glass, and numerous rearview mirrors, visibility is optimized to enable quick and efficient digging.
Maximum Transport Height | 3110 mm – 10 ft 2 in. |
Overall Undercarriage Width | 2690 mm – 8 ft 10 in. |
Transport Length Mono Boom | 8650 mm – 28 ft 5 in. |
Tailswing Radius | 2550 mm – 8 ft 4 in. |
Ground Clearance | 470 mm – 19 in. |
Length Overall Undercarriage | 3920 mm – 12 ft 10 in. |
Mono Boom Digging Reach | 9330 mm – 30 ft 7 in. |
Width Over Fixed Tracks | 2690 mm 8 ft 10 in. |
Mono Boom Dig Height | 9130 mm – 29 ft 11 in. |
Mono Boom Dump Height | 6400 mm – 21 ft |
Mono Boom Ground Level Reach | 9160 mm – 30 ft 1 in. |
Dig depth – 2.44m / 8’ft flat bottom | 6270 mm – 20 ft 7 in. |
Mono Boom Dig Depth | 6490 mm – 21 ft 4 in. |
Standard Dipper | 3100 mm – 10 ft 2 in. |
Capacity
A pair of large fuel tanks ensure that you’ll have enough fuel to finish the day’s tasks. The 500- and 5,000-hour oil-service intervals mean less time is spent performing maintenance. The new version, on the other hand, changes all types of hydraulic oils at the same time. Not only does this simplify your oil change system, but it also saves you time.
Fuel Tank | 285 Lt – 75,3 gal |
Standard Dipper | 3100 Lt – 2 inches |
Weight
Operating Weight | 17945 kg – 39526 Ibs |
With Full Fuel Tank | 79 kg – 175 Ibs |
Operator, and 914 mm (36 in.) | 0.60-m3 – 0.78 cu. yd / 528-kg – 1,164 lbs |
General Purpose Bucket | 3.10-m / 10 ft. 2 in. |
Arm | 3200 kg / 7,055 lbs |
Undercarriage With Triple Semi Grouser Shoes 600mm | 6316 kg / 13,912 lbs |
Undercarriage With Triple Semi Grouser Shoes 700mm | 6530 kg (14,383 lb.) |
Boom With Arm Cylinder | 1300 kg / 2,863 lbs |
Arm With Bucket Cylinder and Linkage 2.60 m (8 ft. 6 in.) | 788 kg / 1,736 lbs |
Arm With Bucket Cylinder and Linkage 3.10 m (10 ft. 2 in.) | 874 kg / 1,925 lbs |
Boom-Lift 2 Cylinders, Total Weigh | 306 kg / 674 lbs |
John Deere 160 Excavator is both smart and quiet. It’s designed to do more work on less fuel with less noise, and at a lower cost than machines that just aren’t as smart. And we’re not just talking about the first 160s on the market, we’re talking about each and every one of them. When you’re doing the kind of hard work that leaves others exhausted, it’s critical to have an excavator that works as hard as you do.Performance
Features
Reliability
Drive
Price
The information presented here will help you decide if this product is the best fit for your situation. Though we do our best to provide all the information you need, things can always change. So be sure to do your own research before purchasing a vehicle, because the information in this review may become outdated over time. If you would like exact details, please contact the vendor directly.
