Kubota 80 excavator makes digging simple for anyone. This small-scale excavator lets you work smarter instead of harder, so you can get the job done fast and efficiently. Easy to control, Kubota KX 80 has a 66.4 horsepower V3307-CR-TE-4 engine that is equipped with a 13,483 lb weight. This makes moving and digging a breeze compared to the other heavier Kubota models.
KX 80 Kubota Excavator can turn hard soil into a soft and muddy state in half the time it would take you with a regular bulldozer. Kubota 80 excavator has optimum visibility to make working easier. The machine also has a new angled blade, making work in tight spaces a breeze. Kubota 80 excavator will dig deeper and wider than any other excavator in its class.
Better fuel economy, fewer exhaust fumes, and improved ergonomics are just a few of the outstanding features of KX 80 excavator. It is also quieter and smoother to operate. Kubota 80 excavator will save you money on fuel, lessen your environmental impact, and give you a more comfortable working environment. It has a two-speed drive, which means that you can dig more quickly and then switch to a slower gear for more careful digging.
The Kubota 80 offers the best features, including an easy attachment on or off the machine. You can change between SAE and ISO operating patterns.
Kubota 80 Excavator Specs
Engine
The 80KX Excavator features the Common Rail System, which electronically controls the fuel injection timing and amount in stages rather than all at once for optimal combustion. The Common Rail System is great because it means better efficiency and better fuel economy and less engine noise.
Engine Features
| Brand | Kubota |
| Model | V3307-CR-TE5 |
| Type | Diesel, water-cooled |
| Number of Cylinders | 4 |
| Power Measured | 2600 RPM |
| Aspiration | Turbocharged |
| Combustion System | Direct injection |
| Fuel System | Common rail system |
Engine Specs
| Specs | US | Metric |
|---|---|---|
| Gross Power | 66.6 HP | 49.7 kW |
| Net Power | 62.3 HP | 46.5 kW |
| Displacement | 203.3 cu in. | 3331 cc |
| Bore | 3.70 in. | 9.4 cm |
| Stroke | 4.72 in. | 12.0 cm |
| Rated Output @2600 RPM | 74.3 HP | 55.4 kW |
| Maximum Torque @1500 RPM | 195.5 Ib-ft | 265 Nm |
| Dry Weight | 672 Ibs | 305 kg |
Engine Dimensions
| Dimension | US | Metric |
|---|---|---|
| L X W X H without aftertreatment unit | 25.8 X 22.1 X 29.6 in. | 65.5 X 56.1 X 75.2 cm |
| L X W X H with aftertreatment unit | 33.7 X 22.1 X 29.6 in. | 85.6 X 56.1 X 75.2 cm |
Drive System
The Kubota 80 Excavator has a compact undercarriage and reduced rear overhang, making it much easier to transport between job sites and much more stable in tight conditions.
| US | Metric | |
|---|---|---|
| Maximum Traction Force | 15062 Ibf | 6832 kgf |
| Tumbler Distance | 7’6.6” ft in. | 230 cm |
| Crawler Lenght | 9’6.2” ft in. | 290 cm |
| Shoe width Rubber | 17.7” ft in. | 45 cm |
| Ground Contact Pressure | 5.3 psi | 0.37 kgf/cm2 |
| Max. Speed | 3.0 mph | 4.8 km |
Hydraulic System
The KX080 excavator is equipped with two auxiliary circuits for proportional flow control. Adjusting the flow of each circuit can be done by simply turning a dial. On and off buttons enable easy operation of special equipment.
| US | Metric | |
|---|---|---|
| Pump Cap. | 44.6 GPM (22.3×2 GPM) | 169.2 L (84.6×2 L) |
| Hydraulic Flow | 26.4 GPM | 100 L |
| Maximum Breakout Force Bucket | 14660 Ibf | 6650 kgf |
| Maximum Breakout Force Arm | 8565 Ibf | 3885 kgf |
Dimensions
| Dimension | US | Metric |
|---|---|---|
| Length | 254 in. | 645 cm |
| Height | 97.5 in. | 247.6 cm |
| Width | 86.6 in. | 220 cm |
| Minimum Ground Clearance | 14 in. | 355 cm |
Working Range
| US | Metric | |
|---|---|---|
| Maximum Digging Height | 287.4 in. | 730 cm |
| Maximum Dumping Height | 206.7 in. | 525 cm |
| Maximum Digging Depth | 181.1 in. | 460 cm |
| Minimum Tail Turning | 57.5 in. | 146 cm |
Weight
| Weight | US | Metric |
|---|---|---|
| Operating weight Rubber (including operator) | 18596 Ibs | 8435 kg |
| Operating weight Steel (including operator) | 18706 Ibs | 8485 kg |
Kubota 80 Excavator Reviews
KX85 is an excellent choice for anybody in search of a small, compact all-terrain vehicle. It’s great for beginners and can be driven in the city or out on rough terrain with equal effectiveness. It also makes for a great recreational vehicle, as it’s safe, easy to control, and fast. With a low seat height, lightweight design, and powerful engine, the KX85 is great for exploring.
This Kubota KX80 excavator is safe, easy to operate, and the perfect foundation for your next project. Not only will it get the job done, but you’ll get it done on time and on budget.Kubota 80 Excavator Review
Performance
Features
Reliability
Drive
Price
The information presented here will help you decide if this product is the best fit for your situation. Though we do our best to provide all the information you need, things can always change. So be sure to do your own research before purchasing a vehicle, because the information in this review may become outdated over time. If you would like exact details, please contact the vendor directly.
