Komatsu PC360 delivers fast, efficient productivity for the medium-duty contractor. The Komatsu 360 excavator has a powerful Komatsu EU Stage V engine, a closed center load sensing hydraulic system, and a comfortable cab, allowing operators to get the most out of this dependable machine. The PC 360 Komatsu is designed to work in conjunction with hydraulic pumps, increasing efficiency, and precision during single and combined movements.
The Komatsu PC 360 LC has two boom mode settings: Power and Smooth. The Power setting is for digging through rock or earthy soil, while the Smooth setting is for gathering material from a site, such as sand or gravel, and for fine grading operations. When needed, the machine’s PowerMax system temporarily raises the Power setting to make the motor work harder.
The Komatsu 360 lc offers drivers a comfortable, ergonomic work environment. The driver’s seat can be adjusted for maximum comfort, and the controls are straightforward.
Komatsu 360 Specs
| Brand | John Deere |
| Model | PC360LC-11 |
| Series | PC series |
| Type | Hydraulic excavator |
| Years Made | 2015-2022 |
Engine
| Brand | Komatsu |
| Model | SAA6D114E-6 |
| Type | Diesel |
| No. of Cylinders | 6 |
| Emissions | Tier 4/EU Stage IV |
| Aspiration | Turbocharged |
| Combustion | Direct Injection |
| Fuel system | Common Rail Fuel Injection |
| Air Filter | Double element type |
| Cooling | Suction type |
| Rated Power | 1950 RPM |
| Specs | US | Metric |
|---|---|---|
| Gross Power | 271 HP | 202 kW |
| Net Power | 257 HP | 192 kW |
| Displacement | 542 cu in. | 8885 cc |
| Bore and Stroke | 4.5×5.7 in. | 11.4×14.5 cm |
| Engine Oil Capacity | 10.2 gal | 38.5 L |
| Coolant Capacity | 9.8 gal | 37 L |
| Fuel Capacity | 159.8 gal | 605 L |
Komatsu 360 Excavator Lifting Capacity
Canopy and Standard Counterweight
| Arm Lenght | Over Front | Over Side |
|---|---|---|
| 4,0 m | 5660 kg 12480 lbs | 4650 kg 10250 lbs |
Komatsu 360 Excavator Weight
| US | Metric | |
|---|---|---|
| Operating weight | 79,366 lbs | 36,000kg |
Performance
| Arm Lenght | 2,2 m | 4,0 m |
|---|---|---|
| Max. Digging Reach | 10.2 m 33.6 ft | 11.9 m 39.0 ft |
| Max. Digging Depth | 6.4 m 21.0 ft | 8.2 m 26.9 ft |
| Max. Dumping Height | 6.6 m 21.7 ft | 7.5 m 24.6 ft |
| Max. Digging Height | 9.6 m 31.5 ft | 10,6 m 34.8 ft |
Swing System
| Swing Speed | 9.5 RPM |
| Swing Torque | 103 kNm |
Travel Speed
| US | Metric | |
|---|---|---|
| Low Speed | 2.0 mph | 3.2 km |
| High Speed | 3.1 mph | 5.5 km |
Hydraulic system
| US | Metric | |
|---|---|---|
| Pump Flow (2x pump) | 2×70.6 GPM | 2×267.5 LPM |
| Hydraulic Tank | 49.7 gal | 188.0 L |
Dimensions
| US | Metric | |
|---|---|---|
| O/A Height of Cabin | 124 in. | 316 cm |
| O/A Lenght | 231 in. | 588 cm |
| O/A Width with 60 cm shoes | 126 in. | 319 cm |
| Tail Swing Radius std arm. | 136 in. | 345 cm |
| Upperstructure Width | 118 in. | 300 cm |
| Ground Clearance | 20 in. | 50 cm |
The Komatsu Pc360 is a fantastic machine as long as the exhaust pressure sensor tube is not clogged.Komatsu Pc360 Review
