Kubota B7100 tractor is a small wheeled tractor developed by Kubota. The Kubota B7100 tractor was known as the Kubota B7100 in some parts of the world. It had some minor upgrades over its predecessor, the Kubota B6700. Looking for Kubota B7100 specs, technical details specifications like an engine, transmission, hydraulic system, electrical, tires, dimensions, attachments and loader lift capacity, etc? You are in the right place.
The Kubota B7100 is a compact utility tractor that was built by Kubota from 1976 to 1985 and fitted with a 3-cylinder diesel engine. This tractor’s unsynchronized gear transmission makes it more compact and faster than other similar models. The Kubota B7100 uses manual steering, brakes with a mechanical expanding shoe, open hydraulics and foot pedal differential lock. With an open operator station, the Kubota B7100 has open hydraulics.
The Kubota B7100 tractor is an economical, cost-effective choice for almost any need. I bought this Kubota for my own personal use after admiring other similar models at work. I find it quiet, easy to navigate and the cabin is comfortable. They are super fuel-efficient, great for small to medium size jobs, and are easy to handle. The engine makes a sound that's hard to resist.Kubota B7100 Review
Performance
Features
Reliability
Drive
Price
Kubota B7100 Specs
Engine
The B7100 utility tractor used a three-cylinder liquid-cooled diesel engine that produced 16 horsepower at 3,000 rpm and 22 pound-feet of torque at 1,800 RPM. The B7100 Kubota displacement was 762 cc. The cylinder bore was 68 millimeters and the stroke was 70 millimeters.
Engine Brand | Kubota |
Engine Model | D750-A |
Engine Type | Diesel, liquid-cooled |
Number of Cylinders | 3 cylinders |
Total Displacement | 762 cc – 46.5 cu. in. |
Power | 11.7 kW – 16 HP – 2800 RPM |
Bore and Stroke | 68×70 mm – 2-5/8 x2-3/4 in. |
Starter | 12V, 0.8 kW electric starter with battery, the glow of ug, and decompression device. |
Cooling | Natural circulation – Water with pressurized radiator. |
Lubrication | Forced lubrication by arachnoidal pump |
Battery | 12V – 45 ah |
Capacity
US | Metric | |
Fuel Tank Capacity | 3.4 gal | 13 liters |
Engine Oil Case Capacity | 4.1 quarts | 3.9 liters |
Engine Coolant Capacity | 4.9 quarts | 4.6 liters |
Transmission
The Kubota B7100’s transmission doesn’t have synchros or a slip clutch. It has 6 forward gears and 2 reverse gears.
Transmission Type | Gear type |
Steering | Ball screw |
Clutch | Dry single plate typle |
Speed Changes | 6 forward, 2 reverse |
Transmission Oil Case Capacity | 12.2 quarts – 11.5 liters |
Differential Type | Bevel gear type |
Travelling Speed
Mph | Km/h | |
1st Forward | 0.62 | 1.0 |
2nd Forward | 1.1 | 1.7 |
3rd Forward | 1.8 | 2.9 |
4th Forward | 2.9 | 4.6 |
5th Forward | 4.8 | 7.8 |
6th Forward | 8.3 | 13.4 |
1st Reverse | 0.9 | 1.5 |
2 nd Reverse | 4.2 | 6.7 |
Dimensions
US | Metric | |
Lenght | 78-3/4 in. | 200 cm |
Width | 40 in. | 101.5 cm |
Height | 45-1/2 in. | 111.5 cm |
Wheel Base | 49-1/8 in. | 125 cm |
Min. Ground Clearance | 11-3/8 in. | 29 cm |
Treads Front | 32-31/64 in. | 82.5 cm |
Treads Rear | 25-19/32 in. – 27-9/16 in. | 65 cm – 70 cm |
Tires
Front Tires | 20.5×8.00-10 |
Rear Tires | 29×12.00-15 |
4WD Front Standard Tires | 6×12 |
4WD Rear Standard Tires | 8×16 |
Weight
US | Metric | |
Weight | 1080 Ibs | 490 kg |
Kubota B1630 Loader Specs
US | Metric | |
Height to pin | 69.2 in. | 1750 mm |
Clearance dumped bucket | 54.1 in. | 1370 mm |
Dump reach | 21 in. | 530 mm |
Dump Angle | 39° | 39° |
Reach Ground | 47 in. | 1200 mm |
Breakout Force | 950 lbs | 430 kg |
Lift to Full Height at Pin | 580 lbs | 263 kg |
Bucket Width (Availability) | 42 in, 48 in, 54 in. | 1060 mm, 1210 mm, 1370 mm |
The information presented here will help you decide if this product is the best fit for your situation. Though we do our best to provide all the information you need, things can always change. So be sure to do your own research before purchasing a vehicle, because the information in this review may become outdated over time. If you would like exact details, please contact the vendor directly. If you need Kubota B7100 manual, please specify by commenting.
