Cat 953 track loader is a multi-purpose track loader capable of performing a variety of tasks in a landfill or transfer station. Caterpillar 953 loader can be used for waste pushing, shredding, and pre-compaction. For added versatility, track loaders are also ideal for creating and maintaining access, digging wells, and digging, carrying, and spreading cover material. The track system can also operate on any terrain, including soft surfaces like sand or gravel.
Cat 953 Specs
| Brand | Cat |
| Model | 953 |
| Type | Track loader |
| Years Made | 1987-Today |
Engine
| Brand | Caterpillar |
| Model | C7.1 |
| Emissions | EPA Tier 4 Final, EU Stage V |
| Build Number | 12A |
| No. of Cylinders | 6 |
| Type | Diesel 4 stroke |
| Aspiration | Turbocharged, TTA |
| Combustion System | Direct Injection |
| Rotation | Counterclockwise |
| Compression Ratio | 16.5:1 |
| Rated Speed | 1800 RPM |
| US | Metric | |
|---|---|---|
| Horsepower (gross) | 173 HP | 129 kW |
| Horsepower (net) | 160 HP | 119 kW |
| Displacement | 428 cu in. | 7010 cc |
| Bore | 4.1 in. | 10.5 cm |
| Stroke | 5.3 in. | 13.5 cm |
| Fuel Tank Capacity | 70 gal | 265 L |
| Engine Oil Capacity | 4.5 gal | 17 L |
| Coolant Capacity | 8.5 gal | 32 L |
Engine Dimensions and Weight
| US | Metric | |
|---|---|---|
| Length | 41.9 in. | 106.4 cm |
| Width | 32.3 in. | 82.0 cm |
| Height | 35.7 in. | 90.7 cm |
| Dry Weight | 1576 lbs | 715 kg |
Transmission
| Transmission | Hydrostatic |
| Gear | Infinite |
Performance
| US | Metric | |
|---|---|---|
| Bucket Capacity – General Purpose | 2.4 yd³ | 1.8 m³ |
| Rated Operating Capacity | 8200 lbs | 3700 kg |
| Tipping Load | 23500 lbs | 10600 kg |
| Bucket Width | 98 in. | 248 cm |
| Breakout Force | 32000 lbs | 142 kN |
| Max. Travel Speed | 6.2 mph | 10 km |
Cat 953 Weight
| US | Metric | |
|---|---|---|
| Operating Weight | 36600 lbs | 16600 kg |
| Shipping Weight | 30200 lbs | 13700 kg |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 41 GPM | 155 LPM |
| Std. System Pressure | 4061 psi | 280 Bar |
| Hydraulic Oil Capacity | 18.5 gal | 70 L |
Dimensions
| US | Metric | |
|---|---|---|
| Std. Machine Width | 91 in | 232 cm |
| Std. Shoe Width | 20 in. | 48 cm |
| Height to Top of Cab | 124 in. | 316 cm |
| Hinge Pin Height | 142 in. | 361 cm |
| Length to Front of Tracks Including Rear Bumper | 178 in. | 452 cm |
| Overall Shipping Length Without Bucket | 202 in. | 512 cm |
| Turning Radius | 142 in. | 361 cm |
Ripper
The Cat 953 features radial rippers.
| US | Metric | |
|---|---|---|
| Weight | 1306 lbs | 592 kg |
| Maximum Clearance Raised | 29.3 in. | 74.5 cm |
| Maximum Penetration | 9.9 in. | 25.3 in. |
| Overall Ripping Width | 77 in. | 195 cm |
| Maximum Penetration Force | 33,212 lbf | 148 kN |
| Maximum Pry Out Force | 19,363 lbf | 86 kN |
We thoroughly examined Cat 953 loader users. They claim to have used the Cat 953 track loader for a long time and that it has a long service life. Except for a few minor part replacements, they don't have many expenses. They are generally pleased with the engine and transmission, and they also have a 10% better fuel economy than their competitors.Cat 953 Review
Performance
Features
Reliability
Drive
Price
The information presented here will help you decide if this product is the best fit for your situation. Though we do our best to provide all the information you need, things can always change. So be sure to do your own research before purchasing a vehicle, because the information in this review may become outdated over time. If you would like exact details, please contact the vendor directly. If you need Cat 953 manual, please specify by commenting.
