Cat 303 excavator packs a lot of power into a compact machine. The 303 Cat excavator is a small, lightweight machine that packs a punch in terms of power and performance. It was designed with low operating costs in mind, with features like auto-idle, auto engine shutdown, and efficient hydraulics with a variable displacement pump. The 303 Caterpillar excavator is the right fit for a variety of hard-working jobs.
Cat 303 Specs
Brand | Caterpillar |
Model | 303 CR |
Series | CR series |
Type | Mini excavator |
Years Made | 2003-2017 |
Engine
Brand | Cat |
Model | C1.1 Turbo |
Type | Diesel V, liquid-cooled |
No. of Cylinders | 3 |
Emissions | EPA Tier 4 Final, EU Stage V |
Compression Ratio | 23.0:1 |
Combustion | Indirect Injection |
Aspiration | Turbocharged |
Rotation | Counterclockwise |
Fuel system | Inline pump |
Rated Speed | 2400 RPM |
Torque Speed | 1600 RPM |
Specs | US | Metric |
---|---|---|
Horsepower (gross) | 18.4 HP | 24.7 kW |
Horsepower (net) | 17.6 HP | 14.7 kW |
Torque Power | 63.0 lbs-ft | 85.4 Nm |
Displacement | 69.0 cu in. | 1130 cc |
Bore and Stroke | 3.0×3.2 in. | 7.7×8.1 cm |
Coolant Capacity | 1.1 gal | 4.0 L |
Engine Oil Capacity | 1.1 gal | 4.0 L |
Fuel Tank Capacity | 11.9 gal | 45.0 L |
Engine Dimensions
US | Metric | |
---|---|---|
Length | 19.7 in. | 50.0 cm |
Width | 20.2 in. | 51.3 cm |
Height | 23.1 in. | 58.8 cm |
Engine Weight
US | Metric | |
---|---|---|
Dry Weight | 238 lbs | 108 kg |
Performance
US | Metric | |
---|---|---|
Maximum Traction Force (high speed) | 3305 lbf | 14.7 kN |
Maximum Traction Force (low speed) | 7059 lbf | 31.4 kN |
Digging Force Std. Stick | 3752 lbf | 16.6 kN |
Digging Force L. Stick | 3327 lbf | 14.8 kN |
Digging Force (bucket) | 6385 lbf | 28.4 kN |
Dig Depth | 104.3 in. | 265.0 cm |
Maximum Dig Height | 177.6 in. | 451.0 cm |
Maximum Dump Clearance | 124.8 in. | 317.0 cm |
Max. Reach | 196.1 in. | 498.0 cm |
Maximum Blade Height | 15.2 in. | 38.5 cm |
Maximum Blade Depth | 21.1 in. | 53.5 cm |
Boom Swing Right | 34.3 in. | 87.0 cm |
Boom Swing Left | 25.2 in. | 64.0 cm |
Boom Swing L | 75° |
Boom Swing R | 50° |
Swing Speed | 9.0 RPM |
Lifting Capacity
Lifting Capacities Blade Down | 0 ft | 3355 lbs | 1522 kg |
Lifting Capacities Blade Down | 9 ft | 1746 lbs | 792 kg |
Lifting Capacities Over Side | 0 ft | 1210 lbs | 549 kg |
Lifting Capacities Over Side | 9 ft | 1426 lbs | 647 kg |
When calculating the Cat 303 lifting capacity, Cabin and standard stick performances are taken as a basis.
Travel Speed
US | Metric | |
---|---|---|
Low Speed | 2.8 mph | 2.6 km |
High Speed | 1.6 mph | 4.5 km |
Hydraulic system
US | Metric | |
---|---|---|
Pump Flow | 26 GPM | 100 LPM |
Auxiliary Hydraulic Flow | 17 GPM | 65 LPM |
Auxiliary Pressure | 3553 psi | 245 Bar |
Cat 303 Weight
US | Metric | |
---|---|---|
Max. Operating Weight with Canopy | 6667 lbs | 3025 kg |
Max. Operating Weight with Cabin | 7552 lbs | 3426 kg |
Shipping Weight with Canopy | 6791 lbs | 3080 kg |
Shipping Weight with Cabin | 7012 lbs | 3181 kg |
Dimensions
US | Metric | |
---|---|---|
O/A Height | 97.6 in. | 248.0 cm |
O/A Length | 177.6 in. | 451.0 cm |
Track Width | 61.0 in. | 154.9 cm |
Undercarrige
US | Metric | |
---|---|---|
Undercarriage Length | 81.5 in. | 207 cm |
Track Shoe Width | 11.8 in. | 30.0 cm |
Ground Clearance | 12.2 in. | 31.0 cm |
The reduced radius of the upper and lower body gives the Cat 303 mini excavator stability and maneuverability in a compact machine. 303 Cat excavators provide exceptional stability in a small package. The upper body is always within the width of the undercarriage, so there is no tail swing and you can work in tight spaces with confidence.Cat 303 Review
