John Deere X300 tractors let you work the way you want. It features three different Accel Deep Mower Decks, plus optional one-touch MulchControl Technology. That makes it a versatile tractor for every season, including mulching leaves and bagging grass clippings. And with attachments for mowing, snow removal, tilling, and more, you can make the most of your yard all year long.
The John Deere x300 series tractors have a twin-touch transmission system with two-pedal foot control for smooth speed and direction changes. The electronic fuel gauge makes it easy to monitor your fuel levels.
John Deere X300 Specs
JD x300 tractor offers an 18.5 hp (13.8 kW) engine and a wide range of features, including four-wheel drive or two-wheel drive and manual or power transmission, making it ideal for short mowing areas or smaller lawns.
| Brand | John Deere |
| Model | X300 |
| Type | Lawn tractor |
| Series | Select X300 Series |
| Years Made | 2006-2015 |
| Manual 2WD Model | John Deere X300 |
| Manual 4WD Model | John Deere X304 |
| Power 2WD Model | John Deere X310 |
John Deere X300 Engine Specs
| Brand | Kawasaki |
| Model | FS600V |
| Type | 4-stroke gasoline, air-cooled |
| No. of Cylinders | 2 |
| Direction of Rotation | Counterclockwise facing the PTO shaft |
| Compression Release | Automatic compression release |
| Ignition | Transistorized-flywheel magneto |
| Lubrication | Pressure feed by positive displacement pump |
| Rated Speed | 3600 RPM |
| Low Idle Speed | 1550 RPM |
| Combustion | High-pressure common-rail direct injection |
| Cooling System | Forced air cooling by fan |
| Air Cleaner | Dual-stage element, dry type |
| Fuel Pump | Diaphragm type pulse pump |
| Starter | 12V electric |
| US | Metric | |
|---|---|---|
| Horsepower | 18.5 HP | 13.8 kW |
| Displacement | 36.8 cu in. | 603 cc |
| Bore and Stroke | 2.9×2.8 in. | 7.3×7.2 cm |
| Engine Oil Capacity | 2.1 qts | 2.0 L |
| Ignition Coil Air Gap | 0.010-0.016 in. | 0.25-0.40 mm |
| Valve Clearance | 0.003 – 0.005 in. | 0.075 – 0.125 mm |
| Spark Plug Gap | 0.030 in. | 0.75 mm |
| Spark Plug Torque | 15 lb-ft. | 20 N-m |
| Fuel Capacity | 3.3 gal | 12.5 L |
Engine Dimensions
| US | Metric | |
|---|---|---|
| Lenght | 19.1 in. | 48.6 cm |
| Width | 16.9 in. | 42.9 cm |
| Height | 14.3 in | 36.2 cm |
Engine Weight
| US | Metric | |
|---|---|---|
| Dry Weight | 80.9 Ibs | 36.7 kg |
Transmission
| Transmission | Kanzaki K46 |
| Type | Hydrostatic |
| No. of Gear | Infinite |
Travel Speed
| US | Metric | |
|---|---|---|
| Forward | 5.5 mph | 8.9 km |
| Reverse | 4.0 mph | 6.4 km |
Dimensions
| Overall without Mower Deck | 38 in. | 97 cm |
| Height | 43 in | 109 cm |
| Length | 72 in. | 173 cm |
| Wheelbase | 49.4 in | 125.5 cm |
Tire Size
| Front | 15×6.00-6 |
| Rear | 20×10.00-8 |
Tire Pressure
| US | Metric | |
|---|---|---|
| Front | 14 psi | 97 kPa |
| Rear | 10 psi | 69 kPa |
John Deere X300 Weight
| | US | Metric |
|---|---|---|
| Tractor without Mower Deck | 483 lbs | 219 kg |
| Tractor with 42X Mower Deck | 556 lbs | 252 kg |
| Tractor with 42M Mower Deck | 575 lbs | 261 kg |
John Deere X300 Attachments
It’s time to get out there and start using the John Deere X300 in your garden. X300 John Deere has attachments to help you make an awesome garden tractor. At the same time, I will be listing the models of attachments necessary for a good snow blower.
42 Edge Xtra Mower
| No. of Blade | 3 |
| Rated Power | 2850 to 3200 RPM |
| Sound Levels | 87.4 ± 1 dB (A) |
| US | Metric | |
|---|---|---|
| Cutting Width | 42 in. | 107 cm |
| Blade Nut Torque | 65 lbs-ft | 88 N-m |
| Cutting Height | 1 to 4 in. | 2.5 to 10.2 cm |
42 Edge Mulch Mower
| No. of Blade | 3 |
| Rated Power | 2880 to 3200 RPM |
| Sound Levels | 85.5 ± 1 dB (A) |
| US | Metric | |
|---|---|---|
| Cutting Width | 42 in. | 107 cm |
| Blade Nut Torque | 65 lbs-ft | 88 N-m |
| Cutting Height | 1 to 4 in. | 2.5 to 10.2 cm |
48 Edge Xtra Mower
| No. of Blade | 3 |
| Rated Power | 3891 to 3450 RPM |
| Sound Levels | 90.5 ± 1 dB (A) |
| US | Metric | |
|---|---|---|
| Cutting Width | 48 in. | 122 cm |
| Blade Nut Torque | 50 lbs-ft | 68 N-m |
| Cutting Height | 1 to 4 in. | 2.5 to 10.2 cm |
54 Edge Xtra Mower
| No. of Blade | 3 |
| Rated Power | 3484 to 3450 RPM |
| Sound Levels | 90.5 ± 1 dB (A) |
| US | Metric | |
|---|---|---|
| Cutting Width | 54 in. | 137 cm |
| Blade Nut Torque | 50 lbs-ft | 68 N-m |
| Cutting Height | 1 to 4 in. | 2.5 to 10.2 cm |
John Deere 7007M Snow Blower
| Clearing Width | 44 in. (111.8 cm) |
| Type | Manual |
| Stage | Two |
| Primary Material | Steel |
| Chute Material | Plastic |
| Series | D100 series |
| Color | Yellow |
John Deere X300 Blade
| Size | 44 in. (111 cm) |
| Position | Front-mount |
| Stage | Two |
| Type | Manual |
John Deere X300 Review
Performance
Features
Reliability
Drive
Price
The John Deere x300 tractor is a perfect choice for city dwellers and those with only small lawns. If you have lots of lawn or obstacles to navigate, you may want to choose a different model.
The information presented here will help you decide if this product is the best fit for your situation. Though we do our best to provide all the information you need, things can always change. So be sure to do your own research before purchasing a vehicle, because the information in this review may become outdated over time. If you would like exact details, please contact the vendor directly. If you need John Deere X300 manual, please specify by commenting.
