Searching for Skytrak 6036 specs? You’ve come to the right place. The new 6036 Skytrak offers a lot of advanced controls, which are much easier to operate. Understanding our variety of options can be complicated. But with the sleek, easy-to-use dash of the Skytrak 6036 forklift, you’ll be running your business in no time. Skytrak 6036 telehandler can get more done in less time because of increased boom speeds.
Everything about the Skytrak 8042 is designed to help you get your job done faster. This includes an ergonomic safety cab, so you can focus on the job at hand and not the telehandler. The redesigned cab in the Skytrak 6036 vehicle now includes an armrest that’s integrated into the dash and a new dashboard, which means operators get more work done without having to pay attention to their equipment. When you order a telehandler with 6036 Skytrak, you can have optional air conditioning.
Don’t worry about dropping your load. With the Stabil-Trak system, the operator can comfortably and confidently secure loads. Skytrak 6036’s Optional 74 hp engine meets Tier 4 Final regulations without the use of Diesel Exhaust Fluid (DEF) and thus doesn’t need DEF.
Skytrak 8042 Specs
Brand | Skytrak |
Model | 8042 |
Type | Telehandler |
Years Made | 1996-2021 |
Serial Numbers
2021 Skytrak 8042 | 0160107742 – 0160107871 – 0160107743 – 0160105989 |
2012 Skytrak 8042 | 0160042889 |
2013 Skytrak 8042 | 0160049102 – 160053772 – 0160054004 |
2014 Skytrak 8042 | 160059508 – 160059427 |
2015 Skytrak 8042 | 160067740 – 160067721 – 160067709 – 160067976 |
2016 Skytrak 8042 | 0160074001 |
2010 Skytrak 8042 | 0160039093 |
2008 Skytrak 8042 | 0160035016 |
2006 Skytrak 8042 | 0160019175 |
2005 Skytrak 8042 | 0160010764 |
Engine Specs
Brand | Cummins |
Model | Cummins QSB4.5T |
Type | Diesel |
No. of Cylinders | 4 |
Power Measured | 2500 RPM |
Specs | US | Metric |
---|---|---|
Gross Power | 110 HP | 82 kW |
Max. Torque | 305 lb-ft | 414 N-m |
Displacement | 274 cu in. | 4.5 L |
Fuel Tank | 35 gal | 132 L |
Transmission
Transmission | Hydrostatic |
Type | Powershift |
Gears | 7 (4 forward and 3 reverse) |
Travel Speed
Gear | US | Metric |
---|---|---|
Max. Travel Speed (F4) | 20 mph | 32 km |
Dimension
Dimension | US | Metric |
---|---|---|
Length | 225.1 in. | 570 cm |
Height | 99.3 in. | 250 cm |
Width | 98.05 in. | 246 cm |
Ground Clearance | 17.2 in. | 43.7 cm |
Outside Turning Radius | 154 in. | 392 cm |
Wheelbase | 119.4 in. | 302 cm |
Weights
Weight | US | Metric |
---|---|---|
Operating Weight | 27100 lbs | 12292.35 kg |
Drawbar Pull | 25000 lbs | 11339.81 kg |
Performance
US | Metric | |
---|---|---|
Outside Turning Radius | 156 in. | 3.96 m |
Maximum Reach | 319 in. | 8.1 m |
Maximum Lift Capacity | 503 in. | 12.78 m |
Lift Capacity at Max Reach | 2200 lb | 997.90 kg |
Lift Capacity at Full Height | 6000 lbs | 2721.55 kg |
Frame Leveling | 10° | 10° |
Speed – Maximum Lift | 15 seconds |
Speed – Maximum Telescope In | 14.2 seconds |
Speed – Maximum Lower | 13 seconds |
Speed – Maximum Telescope Out | 16.5 seconds |
The Skytrak 8042 is designed with everything you need to get the job done fast. The sleek design is equipped with various features that are perfect for construction needs.Skytrak 8042 Review
Performance
Features
Reliability
Price
The information presented here will help you decide if this product is the best fit for your situation. Though we do our best to provide all the information you need, things can always change. So be sure to do your own research before purchasing a vehicle, because the information in this review may become outdated over time. If you would like exact details, please contact the vendor directly. If you need Skytrak 8042 manual, please specify by commenting.
