Takeuchi tb260 mini excavator is compact and maneuverable, it’s good for tight spaces like backyards as well as wide open construction yards. It’s powerful enough to handle most tasks efficiently in one pass. The Takeuchi tb260 excavator can dig holes, move dirt, and complete other heavy-duty tasks. Enjoy full control while operating your excavator with the tb260 Takeuchi excavator. This maneuverable machine is designed to increase productivity and enhance comfort. Its smooth hydraulics, accessible serviceability and powerful machine performance are why Takeuchi is one of the leading brands in the industry.
Takeuchi Tb260 Specs
New TB260 from Takeuchi is the first 6-tonne excavator available in this class. This durable machine will work quietly and efficiently, making your job easier! More than just a bigger model in the TB range, the TB260 is more than capable of standing up for itself in a 6-tonne class. The Takeuchi TB260 delivers a high-torque engine to combat tough jobs, an enhanced hydraulic system for faster cycle times, and exceptional overall performance.
Brand | Takeuchi |
Model | Tb260 |
Series | TB series |
Type | Mini excavator |
Serial Numbers | 126000002- ……. 124100003- ……. |
Years Made | 2014-2022 |
Engine Specs
The Takeuchi Tb260 comes with a Yanmar 4TNV84T turbocharged engine, which is fuel-efficient and has automated modes, allowing for better fuel economy.
Brand | Yanmar |
Engine Model No | 4TN84T-BPTB / 4TNV86CT- PTB (124100003 version) |
Type | Diesel |
No. of Cylinders | 4 |
Aspiration | N/A |
Aftertreatment | DPF |
Emissions | Tier 4 |
Combustion | Direct injection |
Rated Speed | 2400 RPM |
Max. Torque | 1560 RPM |
US | Metric | |
---|---|---|
Horsepower | 47.6 HP | 35.5 kW |
Torque Power | 130.5 ft-lb | 177 N-m |
Displacement | 127.6 cu in. | 2090 cc |
Bore and Stroke | 3.46×3.54 in. | 8.8 x 9.0 cm |
Lubrication | 1.95 gal | 7.4 L |
Cooling System | 2.9 gal | 11.0 L |
Fuel Tank Capacity | 21.4 gal | 81.0 L |
Engine Dimensions
US | Metric | |
---|---|---|
Length | 35.2 in. | 89.4 cm |
Width | 21.6 in. | 54.9 cm |
Height | 29.8 in. | 75.7 cm |
Engine Weight
US | Metric | |
---|---|---|
Dry Weight | 463 lbs | 210 kg |
Performance
You can dig up to 1.5 meters below ground level with the TB260’s 27.3 kN digging arm force and 57 kN bucket breakout force. When you need to cut a path through large stones or scoop up extra-heavy loads, the TB260 Takeuchi can excavate wherever you need. The new TB260’s greater reach and digging depth let you get more done on-site. The Takeuchi TB260 is engineered to increase productivity and save fuel by automatically shifting down to idle when the operator stops moving.
US | Metric | |
---|---|---|
Breakout Force Bucket | 12,756 lbs | 5786 kg |
Max. Digging Depth | 153.3 in. | 389.5 cm |
Max. Vertical Digging Depth | 117.3 in. | 298.0 cm |
Max. Dumping Height | 166.1 in. | 422.0 cm |
Slew Radius | 95.3 in. | 242.0 cm |
Ground Pressure (cab) | 4.58 psi | 31.6 kPa |
Ground Pressure (canopy) | 4.37 psi | 30.1 kPa |
Max. Arm Digging Force | 5755 lbs | 2610 kg |
Traction Force | 14006 lbs | 6353 kg |
Hydraulic Pressure | 3480 psi | 24.0 MPa |
Fuel Consumption (65% of Full Load) | 1.6 gal | 6.3 L |
Undercarriage
Traction Motor | Axial Piston |
Traction Drive | Planetary |
Traction | Brake Disc |
Maximum Gradeability | 30° |
Track Width | 15.7 in. | 40 cm |
Ground Contact Length | 80.7 in. | 205 cm |
Ground Pressure | 4.5 psi | 31 kPa |
Takeuchi Tb260 Lifting Capacity
Lifting Capacities Blade Side | 9 ft | 6660 lbs | 3021 kg |
Lifting Capacities Blade Side | 12 ft | 4296 lbs | 1949 kg |
Lifting Capacities Over Side | 9 ft | 3142 lbs | 1425 kg |
Lifting Capacities Over Side | 12 ft | 2080 lbs | 943 kg |
Swing System
Right | 55° |
Left | 78° |
Slew Speed | 9.4 RPM |
Slew Motor Piston | Constant volume piston |
Slew Brake | Slew Brake |
Travel Speed
US | Metric | |
---|---|---|
Low Speed | 1.7 mph | 2.7 km |
High Speed | 3.0 mph | 4.8 km |
Hydraulic System
Total Hydraulic Flow | 45.3 GPM | 171.5 Lpm |
Auxiliary Flow – Primary Circuit | 27.0 GPM | 102.2 Lpm |
Auxiliary Flow – Secondary Circuit | 11.6 GPM | 43.9 Lpm |
Hydraulic System Pressure | 3,480 psi | 24.0 MPa |
Weight
US | Metric | |
---|---|---|
Operating Weight with Cab | 12,125 Ibs | 5,500 kg |
Operating Weight with Canopy | 12,645 lbs | 5,735 kg |
Dimensions
This new compact mini crawler crane gains maximum working space on limited sites. TB260, a totally redesigned mini excavator is engineered to do what larger excavators can do while being vastly more maneuverable, lighter, and easier to operate.
US | Metric | |
---|---|---|
Height | 101.4 in. | 257.5 cm |
Maximum Reach | 246.8 in. | 627.0 cm |
Length | 218.5 in. | 555.0 cm |
Undercarriage Length | 101.4 in. | 257.5 cm |
Track Width | 15.7 in. | 40.0 cm |
Undercarriage Width | 78.7 in. | 200 cm |
Takeuchi Tb260 Price
Model | Hours | Price |
---|---|---|
2014 Takeuchi Tb260 | 1650 | $47,500 |
2015 Takeuchi Tb260 | 1800 | $48,000 |
2016 Takeuchi Tb260 | 1500 | $50,000 |
2017 Takeuchi Tb260 | 650 | $52,000 |
2018 Takeuchi Tb260 | 500 | $55,000 |
2019 Takeuchi Tb260 | 400 | $58,500 |
2020 Takeuchi Tb260 | 200 | $67,000 |
2021 Takeuchi Tb260 | 50 | $69,000 |
2022 Takeuchi Tb260 | New | $77,000 |
Thank you so much for visiting our site today. We hope you find the Takeuchi tb260 price information helpful.
I've been working on a Takeuchi tb260 and have been pleased with the variety of jobs I can do with it. This lightweight, compact crane saves money and space, making it a popular choice for small construction sites. It has much more room than other equipment I've used and gives me plenty of visibility when using it. I have only one complaint: I wish it had more power for cutting.Takeuchi Tb260 Review
Performance
Features
Reliability
Drive
Price
The information presented here will help you decide if this product is the best fit for your situation. Though we do our best to provide all the information you need, things can always change. So be sure to do your own research before purchasing a vehicle, because the information in this review may become outdated over time. If you would like exact details, please contact the vendor directly. If you need Takeuchi Tb260 manual, please specify by commenting.
