The John Deere 325G is a versatile machine with a 74-horsepower diesel engine, offering a rated operating capacity of 3,200 pounds. JD 325G is vertical-lift boom allows for enhanced reach and lift height, making it ideal for loading trucks and placing pallets. The operator station is spacious, ergonomic, and provides good visibility, reducing fatigue. Thanks to John Deere’s rich variety of attachments, the functionality of the John Deere 325G skid steer increases.
John Deere 325G Specs
Manufacturer | John Deere |
Model | 325G |
Type | Compact track loader |
Years Made | 2018-2024 |
Engine
Brand | Yanmar |
Engine Model No | 4TNV98CT |
Type | Diesel |
Emissions | EPA Final Tier 4/EU Stage IV |
No. of Cylinders | 4 |
Aspiration | Turbocharged |
Aftertreatment | DPF |
Emissions | EU Stage V, EPA Tier IV Final |
Combustion | Direct injection |
Lubricating System | Forced lubrication with trochoid pump |
Air Cleaner | Dry dual element |
Rated Speed | 2500 RPM |
Max. Torque | 1800 RPM |
Starter | DC 12 V, 3.0 kW |
Alternator | DC12 V, 55 A |
Battery | 12 V 799CCA |
US | Metric | |
---|---|---|
Gross Power | 74 HP | 55.2 kW |
Net Power | 70 HP | 52.5 kW |
Peak Torque | 280 lb-fts | 280 N-m |
Displacement | 203 cu. in. | 3327 cc |
Bore | 3.85 in. | 9.8 cm |
Stroke | 4.33 in. | 11.0 cm |
Fuel Capacity | 21 gal | 79 L |
Performance
US | Metric | |
---|---|---|
Operating Capacity (Tipp. 35%) | 2590 lbs | 1176 kg |
Operating Capacity (Tipp. 35%) | 3700 lbs | 1680 kg |
Tipping Load | 7400 lbs | 3360 kg |
Boom Breakout Force | 8750 lbs | 3973 kg |
Bucket Breakout Force | 6000 lbs | 2724 kg |
Powertrain
Pump | Axial piston hydrostatic |
Controls | Electrohydraulic |
Brake | Wet disc |
Travel Speed
US | Metric | |
---|---|---|
Single, Standard | 5.8 mph | 9.3 km |
Optional, Low | 5.2 mph | 8.4 km |
Optional, High | 8.2 mph | 13.2 km |
Hydraulic System
US | Metric | |
---|---|---|
Standard Flow | 21 GPM | 78 LPM |
Optional Flow | 32 GPM | 120 LPM |
System Pressure | 3450 psi | 238 Bar |
Dimensions
US | Metric | |
---|---|---|
Length w/o Bucket | 112.3 in. | 285.2 cm |
Length with Bucket | 136.3 in. | 346.2 cm |
Width w/o bucket (12.6 in track) | 71.5 in. | 181.6 cm |
ROBS Height | 81.1 in. | 206 cm |
Height to Hinge Pin | 126.1 in. | 320.3 cm |
Dump Height | 102.1 in. | 259.3 cm |
Dump Reach | 29.7 in. | 75.4 cm |
Ground Clearance | 9.3 in. | 24 cm |
Undercarriage
US | Metric | |
---|---|---|
Track Width (standard) | 12.6 in. | 32.0 cm |
Track Width (optional) | 15.8 in. | 40.0 cm |
Ground Pressure (standard) | 5.7 psi | 39.3 kPa |
Ground Pressure (optional) | 4.7 psi | 32.4 kPa |
Tractive Effort | 8500 lbf | 3859 kgf |
The John Deere 325G is a CTL that can do a lot of difficult jobs with its power. The compatibility of various attachments makes it versatile (if you want to review the attachments that are equipped, it's quite common on Youtube, you can review it). But since the price of the JD 325G is a little high, it does not seem very suitable for small businesses or personal use. As an alternative, I recommend that you review the following compact track loaders: Bobcat T595, CAT 259D 3, Case TR310, New Holland C337, and Kubota SVL75-2.John Deere 325G Review
Lifting Capacity
Engine
Hydraulics
Drive
Price
The information presented here will help you decide if this product is the best fit for your situation. Though we do our best to provide all the information you need, things can always change. So be sure to do your own research before purchasing a vehicle, because the information in this review may become outdated over time. If you would like exact details, please contact the vendor directly.
