I was surprised that the new cabin of the Kubota U35-4 was more spacious, comfortable, and complete than it looked. I am sure that you will work comfortably and quickly with this 3.5-ton, tiny monster. Moreover, the fact that I can do this with the latest technology in narrow spaces is simply amazing!
The Kubota U35-4 mini excavator I also found its automatic transmission very successful. He gave me the strength I needed—no more, no less. As you are already aware, the engine boasts Kubota power, enabling you to comfortably complete the task! Finally, there are too many attachment options available. The Kubota U35 excavator is comfortable, powerful, and functional. Worth checking out!
Kubota U35-4 Specs
Engine Specs
| Brand | Kubota |
| Model | D1703M-DI-E4 |
| Type | Diesel water-cooled |
| No. of Cylinders | 3 |
| Emission Regulation | Tier 4 |
| Aspiration | Naturally aspirated |
| Combustion | Indirect injection |
| Fuel system | In-line pump |
| Aftertreatment | DOC + DPF |
| Rated Power | 2200 RPM |
| Torque Power | 1800 RPM |
| Specs | US | Metric |
|---|---|---|
| Gross Power | 24.8 HP | 18.5 kW |
| Net Power | 23.9 HP | 17.8 kW |
| Displacement | 100.5 cu in. | 1647 cc |
| Bore and Stroke | 3.43×3.64 in. | 8.7×9.2 cm |
Engine Dimensions
| US | Metric | |
|---|---|---|
| Length | 35.2 in. | 89.4 cm |
| Width | 21.6 in. | 54.9 cm |
| Height | 29.8 in. | 75.7 cm |
Engine Weight
| US | Metric | |
|---|---|---|
| Dry Weight | 141 lbs | 64 kg |
Performance
| US | Metric | |
|---|---|---|
| Max. Breakout Force (Bucket) | 7924 lbs | 3594 kg |
| Max. Breakout Force (Arm) | 4451 lbs | 2019 kg |
| Max. Digging Depth | 117 in. | 297 cm |
| Max. Dumping Height | 133 in. | 337 cm |
| Max. Dig. Height | 191 in. | 484 cm |
| Max. Vert. Digg. Depth | 79 in. | 201 cm |
| Max. Digg. Radius at Ground | 204 in. | 517 cm |
| Ground Pressure Canopy | 4.9 psi | 33.7 KPa |
| Traction Force | 2899.1 lbs | 1315 kg |
Lifting Capacity
Swing System
| Right | 45° |
| Left | 71° |
| Slew Speed | 8.9 RPM |
Travel Speed
| US | Metric | |
|---|---|---|
| Low Speed | 1.9 mph | 3.0 km |
| High Speed | 2.9 mph | 4.6 km |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Capacity (x2) | 10.5 GPM | 39.6 LPM |
| Pump Capacity (x1) | 5.5 GPM | 20.9 LPM |
| Auxiliary Flow | 15.8 GPM | 60.0 LPM |
Fluid Capacity
| US | Metric | |
|---|---|---|
| Hydraulic Oil Reservoir | 11.8 GPM | 44.6 LPM |
| Hydraulic Capacity | 16.1 gal | 61.0 L |
| Fuel Capacity | 12.4 GPM | 46.9 LPM |
Weight
| US | Metric | |
|---|---|---|
| Operating Weight – Rubber | 8129 Ibs | 3687 kg |
| Operating Weight – Steel | 8325 lbs | 3776 kg |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 97 in. | 247 cm |
| Width | 67 in. | 170 cm |
| Length | 187 in. | 475 cm |
| Ground Clearance | 11.3 in. | 28.8 cm |
This mini-excavator amazed me. I rented it for one week. During this time, I moved small trees, dug ditches, shoveled snow, dug ditches 5 feet deep, and opened new roads. It completed them all in surprisingly short periods of time and with success. It was definitely very fun and relaxed. For those who want to buy, my answer is definitely "yes."Kubota U35-4 Review
Lifting Capacity
Engine
Hydraulics
Drive
Specifications
Price
The information presented here will help you decide if this product is the best fit for your situation. Though we do our best to provide all the information you need, things can always change. So be sure to do your own research before purchasing a vehicle, because the information in this review may become outdated over time. If you would like exact details, please contact the vendor directly. If you need Kubota U35-4 manual, please specify by commenting.
