Kubota U55 is a reliable, powerful, and versatile machine in any condition. Kubota U55 4 is a good choice for your business because of its digging and lifting capability, smoother travel performance, and increased versatility. Kubota U55-4 specs a wider cab entrance, more legroom, and a deluxe seat. The use of a roll-over protective structure and a falling object protection structure improves safety. The cab is intended to make tool operation easier, including the use of an optional monitor and joystick.
Kubota U55-4 Specifications
Brand | Kubota |
Model | U55-4 |
Series | U series |
Type | Mini excavator |
Years Made | 2010-2022 |
Engine Specs
Brand | Kubota |
Engine Model No | V2607-CR-E4 |
Type | Diesel V 4 cycle |
No. of Cylinders | 4 |
Emissions | Tier4 + EU Stage V |
Combustion | Direct Injection |
Fuel System | Common rail system |
Fuel Type | Diesel Fuel No.2-DULS |
Firing Order | 1-3-4-2 |
Compression Ratio | 18.0 |
Rotation | Counter-clockwise |
Oil Pressure Indicating | Electrical type switch |
Starter | Electric Starting |
Lubricant | CJ-4 |
Rated Speed | 2200 RPM |
Max. Bare Speed | 2700 RPM |
Low Idle Speed | 800 RPM |
Torque Speed | 1600 RPM |
Starter | 12 V cell starter |
US | Metric | |
---|---|---|
Horsepower | 47.6 HP | 35.5 kW |
Net Power | 45.2 HP | 33.7 kW |
Torque Power | 128.4 ft-lb | 174.1 N-m |
Displacement | 159.6 cu in. | 2615 cc |
Bore and Stroke | 3.4×4.3 in. | 8.7×11.0cm |
Fuel Tank Capacity | 18.0 gal | 68.0 L |
Oil Capacity | 2.2 gal | 10.2 L |
Coolant Capacity | 1.3 gal | 6.0 L |
Starter | 3.4 HP | 2.5 kW |
Engine Dimensions
US | Metric | |
---|---|---|
Length | 24.5 in. | 62.3 cm |
Width | 20.6 in. | 52.2 cm |
Height | 27.6 in. | 70.0 cm |
Engine Weight
US | Metric | |
---|---|---|
Dry Weight | 589 lbs | 267 kg |
Performance
US | Metric | |
---|---|---|
Breakout Force Bucket | 11177 lbs | 5069.8 kg |
Max. Digging Depth | 142.3 in. | 361.5 cm |
Max. Digging Height | 219.7 in. | 558.0 cm |
Max. Dumping Height | 158.3 in. | 402.0 cm |
Max. Vert. Digg. Depth | 59.6 in. | 151.5 cm |
Max. Vert. Digg. Depth | 234.1 in. | 594.5 cm |
Max. Digging Radius | 239.4 in. | 608.0 cm |
Ground Pressure | 4.4 psi | 30.3 KPa |
Traction Force | 14480 lbs | 6568 kg |
Max. Travel Speed | 3.1 mph | 4.9 km |
Tumbler Distance | 78.3 in. | 199.0 cm |
Crawler Length | 98.4 in. | 250.0 cm |
Shoe Width | 15.7 in. | 40 cm |
Lifting Capacity
Swing System
Right | 55° |
Left | 70° |
Swing Speed – Right | 3.6 sec. |
Swing Speed – Left | 4.5 sec. |
Slew Speed | 9.3 RPM |
Hydraulic System
US | Metric | |
---|---|---|
Pump Capacity (pumps x2) | 14.8 GPM | 56.1 LPM |
Pump Capacity (gear x1) | 9.8 GPM | 37.0 LPM |
Hydraulic Flow – AUX 1 | 19.8 GPM | 75.0 LPM |
Hydraulic Flow – AUX 2 | 9.8 GPM | 37.0 LPM |
Hydraulic Oil Reservoir | 11.9 GPM | 45.0 L |
Hydraulic Oil System | 20.9 GPM | 79.0 L |
Weight
US | Metric | |
---|---|---|
Operating Weight Rubber / Canopy | 11,915 Ibs | 5,405 kg |
Operating Weight Rubber / Cabin | 12,115 lbs | 5495 kg |
Dimensions
US | Metric | |
---|---|---|
Height | 100.4 in. | 255.0 cm |
Width | 77.2 in. | 196.0 cm |
Lenght | 216.5 in. | 550.0 cm |
Ground Clearance | 12.2 in. | 31.0 cm |
Blade
Width | 77.2 in. | 196.0 cm |
Height | 16.1 in. | 41.0 cm |
Max. Drop Below Ground | 16.1 in. | 41.0 cm |
Max. Lift Above Ground | 17.3in. | 44.0 cm |
This modern 5.4-tonne equipment is built with outstanding stability to function efficiently even in tight quarters. Kubota U55 4 mini excavator is an excellent pick for your company.Kubota U55 4 Excavator Reviews
Performance
Features
Reliability
Drive
Price
The information presented here will help you decide if this product is the best fit for your situation. Though we do our best to provide all the information you need, things can always change. So be sure to do your own research before purchasing a vehicle, because the information in this review may become outdated over time. If you would like exact details, please contact the vendor directly. If you need Kubota U55 manual, please specify by commenting.
