The 330’s distinctive cab design maximizes visibility while enhancing comfort with ergonomic controls and useful controls. Additionally, with a bucket digging force of 40,200 lbf (179 kN) and a maximum digging depth of 285 in.(724 cm), the 330 is made for heavy haul applications like lifting or digging (285 cm). Automated boom, stick, and bucket movements result in more accurate cuts with less work.
Cat 330 Specs
| Brand | Caterpillar |
| Model | 330 |
| Type | Hydraulic Excavator |
| Years Made | 2019-2022 |
Engine
| Brand | Caterpillar |
| Model | C7.1 |
| Type | Diesel 4 stroke |
| Emissions | EPA Tier 4 Final, EU Stage V |
| Build Number | 12A |
| No. of Cylinders | 6 |
| Aspiration | Turbocharged |
| Combustion System | Direct Injection |
| Rotation | Counterclockwise |
| Compression Ratio | 16.5:1 |
| Rated Speed | 2200 RPM |
| US | Metric | |
|---|---|---|
| Horsepower | 275 HP | 205 kW |
| Displacement | 428 cu in. | 7010 cc |
| Bore | 4.1 in. | 10.5 cm |
| Stroke | 5.3 in. | 13.5 cm |
| Fuel Tank Capacity | 125 gal | 474 L |
| DEF | 11 gal | 41 L |
| Engine Oil Capacity | 7 gal | 25 L |
| Coolant Capacity | 7 gal | 25 L |
Working Ranges
| US | Metric | |
|---|---|---|
| Lifting Capacity | 2315 lbs | 1050 kg |
| Bucket Digging Force | 40,200 lbf | 179 kN |
| Stick Digging Force | 28,300 lbf | 126 kN |
| Reach Boom | 242 in. | 615 cm |
| Reach Stick | 126 in. | 320 cm |
| Digging Depth | 285 in. | 724 cm |
| Vertical Wall Digging Depth | 237 in. | 601 cm |
| Reach at Ground Level | 420 in. | 1068 cm |
| Cutting Height | 395 in. | 1003 cm |
| Loading Height | 274 in. | 695 cm |
Bucket Capacity
| US | Metric | |
|---|---|---|
| Bucket Capacity | 2.3 yd³ | 1.76 m³ |
Dimensions
| US | Metric | |
|---|---|---|
| Cab Height | 120 in | 306 cm |
| Shipping Length | 410 in. | 1042 cm |
| Tail Swing Radius | 123 in. | 313 cm |
| Track Length | 157 in. | 399 cm |
| Transport Width | 126 in. | 319 cm |
| Track Gauge | 102 in. | 259 cm |
| Ground Clearance | 44 in. | 112 cm |
Hydraulic System
| US | Metric | |
|---|---|---|
| Maximum Flow | 148 GPM | 560 LPM |
| Maximum Pressure – Swing | 4320 psi | 298 Bar |
| Hydraulic Tank | 147 gal | 39 L |
| Hydraulic System | 82 gal | 310 L |
Cat 330 Weight
| US | Metric | |
|---|---|---|
| Max. Operating Weight | 69,200 lbs | 31,400 kg |
The Cat 330's undercarriage is strong. Its working capacity is superior to the class average. However, some operators complain about the working speed. In terms of fuel consumption, it also consumes more than its rivals.Cat 330 Review
Reliability
Specifications
Reliability
Drive
Price
The information presented here will help you decide if this product is the best fit for your situation. Though we do our best to provide all the information you need, things can always change. So be sure to do your own research before purchasing a vehicle, because the information in this review may become outdated over time. If you would like exact details, please contact the vendor directly. If you need Cat 330 manual, please specify by commenting.
