Ford 3000 tractor is a stylish tractor that is extremely comfortable to drive. Despite its size and presence, it drives like a sedan and is extremely maneuverable. The cabin is roomy, and it has a way of making any job feel easier than it already is.
My parents purchased the Ford tractor 3000 about 25 years ago when it had just been released in the United States. My parents had a 93-acre farm at the time, and they used this machine for everything from mowing hay to clearing waterways. Simple, completely dependable, and inexpensive to maintain. If I had the opportunity, I would gladly purchase another, but hydraulics are now obsolete. The filter is difficult to reach inside the rear end, and the flow is insufficient for modern-driven applications. The Ford 3000 diesel tractor was introduced in 1965 as part of the 1000 Series.
Ford 3000 Specs
The following is a detailed review of the most recent Ford 3000 tractor, as well as its specifications.
Brand | Ford |
Model | 3000 |
Type | Utility tractor |
Build Year | 1965-1975 |
Engine
Manufacturer | Ford |
Type | Diesel |
No of Cylinder | 3 |
Compression Ratio | 16.5:1 |
Firing Order | 1-2-3 |
Cooling | Pressurized liquid recirculating |
Injection Pump | Inline |
Starter | Positive engagement solenoid operated |
Idle Speed | 600-700 RPM |
Rated Speed | 2000 RPM |
US | Metric | |
---|---|---|
Horsepower | 44.0 HP | 32.8 kW |
Displacement | 175 cu in. | 2868 cc |
Bore | 4.2 in. | 10.7 cm |
Stroke | 4.2 in. | 10.7 cm |
Engine Oil Capacity | 1.5 gal | 5.7 L |
Cooling Capacity | 3.4 gal | 13.0 L |
Fuel Tank Capacity | 13.0 L | 49.2 L |
Transmission
Transmission Variants | Select-O-Speed 4-speed with F/R 8 F and 2 R 6 F and 2 R |
Transmission (Max. Speed) | Forward | Reverse |
---|---|---|
Select-O-Speed | 16.2 mph 26.1 km | 4.6 mph 7.2 km |
4-speed with O/U | 22.6 mph 36.4 km | 5.1 mph 8.2 km |
8 F and 2 R | 17.3 mph 27.8 km | 8.1 mph 13.0 km |
6 F and 2 R | 18.0 mph 29.0 km | 7.3 mph 11.7 km |
Lubricating Oils
Manual Transmission | Ford M2C-85-A SAE 20W/30 SAE 80 E.P |
O Speed Transmission | ESN-M2C41-A |
Rear Axle | Ford M2C-85-A SAE 20W/30 SAE 80 E.P |
Steering Box | Ford Oil M2C-94-A SAE 90 E.P |
Power Steering Reservoir | Ford Oil M2C-92-A SAE 10W |
Belt Pulley | Ford M2C-85-A SAE 20W/30 SAE 80 E.P |
Clutch
Transmission PTO | Single |
Live PTO | Double |
PTO Power | 1800 RPM |
Dimensions
US | Metric | |
---|---|---|
Height to Top of Exhaust | 83 in. | 211 cm |
Height to Hoodline | 53 in. | 135 cm |
Ground Clearance Front Axle | 21 in. | 53 cm |
Ground Clearance Transmission | 13.4 in | 34 cm |
O/A Lenght | 127 in. | 322 cm |
Width Min. Track | 64 in. | 163 cm |
Width Max. Track | 88 in. | 224 cm |
Wheelbase Min. Track | 76 in. | 192 cm |
Turning Radius with Brake | 10.7 ft | 3.4 m |
Turning Radius without Brake | 9.7 ft | 2.9 cm |
Vineyard Dimensions
US | Metric | |
---|---|---|
Height to Hoodline | 53 in. | 135 cm |
Width Max. Track | 54 in. | 138 cm |
Wheelbase min. Track | 77 in. | 195 cm |
Turning Radius with Brake | 10.7 ft | 3.4 m |
Turning Radius without Brake | 9.7 ft | 2.9 m |
Ground Clearance Front Axle | 21.5 in. | 55 cm |
Weight
US | Metric | |
---|---|---|
Operating Weight | 3700 lbs | 1680 kg |
Vineyard Weight | 3590 lbs | 1630 kg |
Narrow Weight | 3150 lbs | 1430 kg |
None of these tractors have had any reliability issues. They do the work required but don't have all the bells and whistles that newer models have. It is one of the best choices you can make among Ford 3000 alternatives.Ford 3000 Specs And Review
Performance
Features
Reliability
Drive
Attachments
The information presented here will help you decide if this product is the best fit for your situation. Though we do our best to provide all the information you need, things can always change. So be sure to do your own research before purchasing a vehicle, because the information in this review may become outdated over time. If you would like exact details, please contact the vendor directly. If you need Ford 3000 manual, please specify by commenting.
