Kubota B6000 specs better performance and reliability than what we’re used to seeing on a machine of this size. The B6000 Kubota has a diesel engine that starts easily, even in cold weather. The cab is extremely comfortable and includes a number of options to control the machine. Fuel efficiency was more important than power and performance, so the Kubota B6000 tractor is small enough to get the job done using less fuel.
Kubota B6000 Specs
Kubota B6000 was produced in the 1970s and was a subcompact-sized utility tractor. The B6000 Kubota is a hard-working, high-quality machine that never quits. It’s built to handle tough work, yet it’s still compact enough for use on small farms and moderate acreages.
| Brand | Kubota |
| Model | Kubota B6000 |
| Type | Sub-compact tractor |
| Series | B series |
| Years Made | 1973-1977 |
Kubota B6000 Engine Specs
Featuring a Kubota ZL600 diesel engine, this Kubota B6000 tractor will provide you with the various power needed to perform tasks in different fields. So the B6000 Kubota tractor will be more than equal to various tasks in dry fields, wet fields, pastures, orchards, and gardens.
Spherical combustion chambers are an innovative feature and have a very positive effect on the engine’s performance and economy. This is a very efficient engine. Equipped with a battery starter, glow plugs, pressurized decompression unit, and a spherical combustion chamber, this model is built to start up instantly.
The ZL600 engine, specially designed for Kubota B6000 tractors, delivers extra power to ensure peak performance under extra overload when the speed is lowered. It will not stall on tough jobs.
| Brand | Kubota |
| Model | ZL600 |
| Type | Diesel water-cooled |
| No. of Cylinders | 2 |
| Rated Speed | 2700 RPM |
| Max. Idle Speed | 2900 RPM |
| Combustion | Spherical type |
| Cooling System | Water with pressurized radiator |
| Lubrication | Forced lubrication by trochoidal pump |
| Starter | 12V electric with battery |
| Battery | 65AH |
| Fuel | Diesel light oil or No.2 diesel oil |
| US | Metric | |
|---|---|---|
| Horsepower | 12.5 HP | 9.3 kW |
| Displacement | 35.31 cu in. | 577 cc |
| Bore and Stroke | 2.76×2.95 in. | 7.0×7.5 cm |
| Fuel Tank Capacity | 2.38 gal | 9.0 L |
| Radiator Capacity | 0.52 gal | 2.0 L |
| Engine Oil Capacity | 1.66 gal | 6.3 L |
Power Take-Off (PTO)
| PTO Location | Transmission case rear and tractor body front |
| PTO Power | 3 stages |
PTO Power
| Stage 1 | 560-840 RPM |
| Stage 2 | 1350 RPM |
| Stage 3 | 2700 RPM |
Transmission
| Transmission | Gear shift |
| No. of Speeds | 8 speed |
| Gear | 6 range forward, 2 range reverse |
Travel Speed
| Gear | US | Metric |
|---|---|---|
| Forward | 7.47 mph | 12.02 km |
| Reverse | 4.18 mph | 6.72 km |
Chassis
| Chassis | 4×2 2WD or 4×4 MFWD 4WD |
| Steering | Worm screw type |
| Clutch | Dry single plate, pedal type |
| Brakes | Internal-expanding type, right & left independent with interlocking device |
| Differential | Bevel gear type (both front and rear) |
Dimensions
| US | Metric | |
|---|---|---|
| Lenght | 71.6 in. | 181.9 cm |
| Height | 43.8 in. | 111.3 cm |
| Width | 36.3 in. | 92.2 cm |
| Wheelbase | 45.6 in. | 115.8 cm |
| Ground Clearance | 10.6 in. | 26.9 cm |
| Treads Front | 29.8~31.5 in. | 75.7~80.0 cm |
| Treads Rear | 28.0~36.3 in. | 71.1~80.0 cm |
Tire Size
| Front | 6-12 |
| Rear | 7-16 |
Weight
| US | Metric | |
|---|---|---|
| Weight | 860 lbs | 390 kg |
Despite its age, the Kubota B6000 tractor has a lot of power and is very useful in our yard. We have very greasy soil and it hasn't gotten stuck once. The 4-star rating is because the PTO only spins in reverse compared to other tractors, but that can be fixed with a PTO reverser or buying older implements. The Kubota B6000 tractor has adequate power and can run almost any task. It is a very useful tool on our farm.Kubota B6000 Review
Performance
Features
Reliability
Drive
Price
The information presented here will help you decide if this product is the best fit for your situation. Though we do our best to provide all the information you need, things can always change. So be sure to do your own research before purchasing a vehicle, because the information in this review may become outdated over time. If you would like exact details, please contact the vendor directly. If you need Kubota B6000 manual, please specify by commenting.
