Bobcat E63 has a high-capacity powertrain with high torque, a low RPM engine, and a broad gear range for optimal productivity in difficult situations. It has a completely automated control system that provides outstanding maneuverability while reducing operator fatigue. Bobcat’s e63 excavator is unrivaled in terms of adaptability, productivity, and efficiency. The Tier 4-compliant e63 is a traditional tail swing model. E63 Bobcat is fully adjustable super deluxe seat will keep you comfy throughout the day.
E63 Bobcat Specs
Manufacturer | Bobcat |
Model | E63 |
Type | Mini excavator |
Years Made | 2013-2022 |
Engine
Brand | Yanmar |
Engine Model No | 4TNE98C |
Type | Vertical In-line Diesel |
No. of Cylinders | 4 |
Aspiration | Natural |
Lubrication | Forced lubrication with trochoid pump |
Cooling System | Water-cooled, belt-driven |
Emissions | Tier 4 |
Combustion | Direct injection |
Rotation | Counterclockwise viewed from flywheel end |
Compression Ratio | 18.0 |
Rated Speed | 2100 RPM |
Max. Torque | 1600 RPM |
Max. Idle Power | 2650 RPM |
Min. Idle Power | 1150 RPM |
US | Metric | |
---|---|---|
Horsepower | 59 HP | 44 kW |
Displacement | 111 cu in. | 3319 cc |
Bore | 3.9 in. | 9.8 cm |
Stroke | 4.3 in. | 11.0 cm |
Fuel Capacity | 21 gal | 79 L |
Oil Capacity | 3 gal | 11.2 L |
Performance
US | Metric | |
---|---|---|
Lifting Capacity | 5900 lbs | 2677 kg |
Digging Force Arm | 5767 lbf | 2616 kg |
Digging Force Bucket | 9700 lbf | 4400 kg |
Lift Radius | 118 in. | 300 cm |
Slew System
Boom Swing Right | 50° |
Boom Swing Left | 70° |
Slew Rate | 9.0 RPM |
Travel Speed
US | Metric | |
---|---|---|
Low Speed | 1.6 mph | 2.6 km |
Max. Speed | 2.9 mph | 4.7 km |
Hydraulic System
US | Metric | |
---|---|---|
Auxiliary Flow | 22.5 gpm | 85.2 Lpm |
Auxiliary Pressure | 3045 psi | 210 Bar |
Dimensions
US | Metric | |
---|---|---|
Length | 226 in. | 574 cm |
Width | 78 in. | 198 cm |
Height | 100 in. | 254 cm |
Working Ranges
US | Metric | |
---|---|---|
Digging Depth | 162 in. | 411 cm |
Cut Height | 168 in. | 427 cm |
Reach at Ground Level | 245 in. | 622 cm |
Weight
US | Metric | |
---|---|---|
Operating Weight | 13800 lbs | 6260 kg |
Bobcat e63 excavator is a powerful and fast excavator, but if you don't need one, it might be a bit pricey.
E63 Bobcat is built for professional construction sites that need to move a lot of material. It's not a good option for homeowners who only need an excavator on rare occasions.
The Bobcat E63 has a lot of power and can handle heavy loads with ease. The engine has a maximum output of 59 horsepower. This makes it extremely useful for jobs requiring the lifting of large amounts of material over long distances.Bobcat E63 Review
Performance
Features
Reliability
Drive
Price
The information presented here will help you decide if this product is the best fit for your situation. Though we do our best to provide all the information you need, things can always change. So be sure to do your own research before purchasing a vehicle, because the information in this review may become outdated over time. If you would like exact details, please contact the vendor directly. If you need Bobcat E63 manual, please specify by commenting.
