1845 Skid Steer Loader delivers advanced performance in extreme conditions. Case 1845 Skid Steer is the class-leading operator comfort skid steer loader designed to increase productivity and profitability in a wide range of general material handling, construction, and landscape applications. Engineered for greater versatility, performance, and reliability, the 1845 Skid Steer Loader has a 56 hp engine with power demand and productivity features. Its Tier 3/Stage IIIA compliant DHC diesel engine makes it EPA Tier 4/Stage IV ready.
Case 1845 skid steer makes maneuvering easier than ever with a lower center of gravity, revised hand control, and improved visibility. A new, asymmetrical tire layout and unique alignment design make steering and tracking straight a breeze.
With the power of a four-cylinder, a large fuel tank, and a three-speed transmission, the Case 1845 skid steer loader is designed to provide exceptional endurance in challenging conditions.
1845 skid steer is ideal for residential and commercial applications, including clearing lots, landscaping jobs, and green belt maintenance.
1845 Case Skid Steer Specifications
Engine
| Brand | Kubota |
| Model | Case 4390 |
| Number of Cylinders | 4 |
| Compression Ratio | 19.1:1 |
| Injection System | Direct |
| Air Filter | Dry-type 2 elements |
| Oil Filter | Flow type |
| Us | Metric | |
| Power SAE JI349 at 2000 RPM | 60 HP | 44.7 kW |
| Power DIN 6271 at 2000 RPM | 56.3 HP | 42 kW |
| Power ECE 80/1269 at 2000 RPM | 56.3 HP | 42 kW |
| Power ISO 9249 at 2000 RPM | 56.3 HP | 42 kW |
| Maximum Torque DIN 6271 at 1300 RPM | 176.47 ft lbf | 240 nm |
| Displacement | 3917 cm2 |
Transmission
| Type | Hydrostatic. Four-wheel drive – chain driven Independent drive system on each side of the machine. |
| Hydraulic System | Pump double body variable displacement pump plus charge pump two motors variable displacement type Filter six-micron capacity, interchangeable with restriction indicator on the instrument panel |
| Travel Speed at Full RPM | 9.70 km(6.0 mph) |
Capacity
| Fuel tank | 85.6 qts | 81.0 l |
| Hydraulic Reservoir (with filter) | 33.81 qts | 32.0 l |
| Chain compartment | 2x 6.0 qts | 2 x 5.7 l |
| Diesel engine (with filter) | 11.0 qts | 10.4 l |
| Cooling system | 18.0 qts | 17.0 l |
Brakes
| Hydrostatic service brake | As soon as travel levers are returned to the neutral position the hydrostatic system ensures automatic braking of the 4 drive wheels |
| Parking and working brakes | The multi-disc wet parking brake is automatically applied when the seat safety bars are raised or the park brake switch is energized |
Steering
| Type | Independent – 360° counter rotation steering controlled by two independent, power-assisted levers |
Loader Performance
| Us | Metric | |
| Tipping load (SAE) | 3494 Ibs | 1585 kg |
| Rated operating load | 1716 Ibs | 792 kg |
Weight
| Us | Metric | |
| Operational Weight | 6197 Ibs | 2811 kg |
Dimensions
| US | Metric | |
| Ground Clearance | 8 in. | 20 cm |
| Height – Top of Cab | 6.7 ft | 2 cm |
| Wheelbase | 3.4 ft | 10 cm |
| Reach at Max Lift and Dump | 23 in. | 58 cm |
| Length w/o Bucket | 8.5 ft | 3 cm |
| Length with Bucket | 11.1 ft | 30 cm |
Bucket
| TYPE | WIDTH | CAPACITY (SAE) | CAPACITY STRUCK | WEIGHT | DUMP HEIGHT | DUMP REACH | DUMP ANGLE | OVERALL LENGTH |
| m | m3 | m3 | kg | m | m | degrees | m | |
| DIRT | 1,85 | 0,39 | 0,30 | 186 | 2,28 | 0,58 | 41 | 3,36 |
| REHANDLING | 1,85 | 0,65 | 0,52 | 225 | 2,17 | 0,76 | 38 | 3,53 |
| SNOW | 2,03 | 0,89 | 0,72 | 267 | 2,12 | 0,76 | 38 | 3,60 |
| 4 in 1 | 1,85 | 0,47 | 0,31 | 312 | 2,20 | 0,48 | 52 | 3,36 |
Measurements, production info, attachments, weight, etc.
The universal skid steers quick hitch allows you to attach a wide range of attachments, with no need for adapters. The self-centering system of the universal skid steers quick hitch is quicker and prevents the potential for kickback. When you need to handle large jobs, rely on the power and durability of the Case 1845 Skid Steer.
Powered by a 57 hp Tier 4 engine, the Case 1845 Skid Steer is powerful enough to handle the toughest jobs, but safe enough for operation by a single operator. The hydraulic system of the Case 1845 Skid Steer is smooth and reliable, letting you work without worry.1845 Case Skid Steer Review
