John Deere 3038e Specs
| Brand | John Deere |
| Model | 3038e |
| Series | 3E Series (Others; 3025E, 3032E) |
| Type | Compact utility tractor |
| Years Made | 2013-2025 (New Version) |
Engine
| Brand | Yanmar |
| Model | 3TNV86CT-NJT2 |
| Type | Diesel turbocharged, water-cooled |
| No. of Cylinders | 3 |
| Emissions | Tier 4 |
| Injection Pump Type | High-pressure common-rail direct injection |
| Fuel Type | Direct injection |
| Lubrication | Pressurized |
| Aspiration | Natural |
| Rated Speed | 2500 RPM |
| Compression Ratio | 19.1:1 |
| Air Cleaner | Dual dry element |
| US | Metric | |
|---|---|---|
| Gross Power | 27.4 HP | 36.7 kW |
| PTO Power | 22.4 HP | 30.0 kW |
| Displacement | 95.7 cu in. | 1.57 L |
| Bore and Stroke | 3.4 x 3.54 in. | 8.6 x 9.0 cm |
| Torque at Rated Speed | 104.7 lb-ft | 77.2 Nm |
| Fuel Tank Cap. | 28.5 gal | 7.5 L |
| Starter Size | 1.9 hp | 1.4 kW |
Transmission
| Transmission | Hydrostatic (Sync Shuttle) |
| Gears | Infinite 2 ranges forward and reverse |
| Brakes | Wet disc |
| Steering | Power steering |
Travel Speed
| US | Metric | |
|---|---|---|
| 1st Forward | 6.7 mph | 10.7 km |
| 2nd Forward | 13.0 mph | 21.0 km |
| 1st Reverse | 6.7 mph | 10.7 km |
| 2nd Reverse | 13.0 mph | 21.0 km |
Dimensions
| US | Metric | |
|---|---|---|
| Width | 61.9 in. | 157 cm |
| Length | 116 in. | 295 cm |
| Height | 95.5 in. | 242 cm |
| Wheelbase | 62.7 in. | 159.6 cm |
| Front Axle Clearance | 12.7 in. | 32 cm |
| Turning Radius without Brakes | 112.8 in. | 290 cm |
Tire Size
| Front Farm | 7-14 |
| Front Turf | 27×8.5-15 |
| Front R4 (type 1) | 25×8.5-14 |
| Front R4 (type 2) | 25×8.5-15 |
| Rear Farm | 11.2-24 |
| Rear Turf | 41×14-20 |
| Rear R4 (type 1) | 15-19.5 |
| Rear R4 (type 2) | 43×16-20 |
Weight
| Weights | US | Metric |
|---|---|---|
| Shipping Weight | 2668 Ibs | 1027 kg |
| Front Axle Capacity | 1940 Ibs | 880 kg |
| Rear Axle Capacity | 2645 Ibs | 1200 kg |
John Deere D160 Loader Specs
Loader Lift Capacity
| US | Metric | |
|---|---|---|
| Lift Capacity at Full Height Measured at Pivot (U) | 1186 lbs | 539 kg |
| Lift Capacity at Full Height Measured at 50 cm Ahead of Pivot (V) | 845 lbs | 384 kg |
Lift and Reach
| US | Metric | |
|---|---|---|
| Maximum Lift Height at Pivot Pin | 84 in. | 214 cm |
| Reach at Maximum Height | 24 in. | 60.5 cm |
Breakout Force
| US | Metric | |
|---|---|---|
| Breakout Force at Pivot Pin | 1,704 lbs | 760 kg |
| Breakout force at 50 cm | 1204 Ibs | 537 kg |
Fast Cycle Times
| Bucket Rollback Time | 1.88 sec. |
| Bucket Dump Time/ Regen | 1.75 sec. |
| Loader Raising and Lowering Time | 2.75 sec. |
| Rollback Angle | 31.4° |
| Dump Angle | 43.8° |
The John Deere 3038e is the top model in the 3e series and it’s not just because of its shiny green paint and sleek black wheels. It’s the perfect combination of power and maneuverability, and it comes equipped with a versatile bucket that can take on any job.
Performance
Features
Reliability
Drive
Attachments
Lifting Capacity
Price
The information presented here will help you decide if this product is the best fit for your situation. Though we do our best to provide all the information you need, things can always change. So be sure to do your own research before purchasing a vehicle, because the information in this review may become outdated over time. If you would like exact details, please contact the vendor directly.
I’ve had my John Deere 3032e tractor for approximately 4 years. It lacked lifting power, however, and I couldn’t move more than a pail of gravel at a time. As a result, I purchased a John Deere 3038e to replace it.
