Bobcat 85G excavator has increased maneuverability for use in tight spaces such as construction sites. JD 85g mini excavator complies with EPA Final Tier 4, EU Stage IV regulations, allowing you to use them confidently now and in the future. Rubber tracks or sealed and lubricated chains with rubber pads or steel semi-grousers are available for 85g John Deere. You can specify the right excavator for your job by choosing from a variety of arm and bucket options.
John Deere 85g Specs
| Brand | John Deere |
| Model | 85g |
| Series | G series |
| Type | Mini excavator |
| Years Made | 2017-2022 |
Engine
| Brand | Yanmar |
| Model | 4TNV98C-WHBW |
| Type | Diesel |
| No. of Cylinders | 4 |
| Emissions | Tier 4/EU Stage IV |
| Aspiration | Natural |
| Combustion | Direct Injection |
| Fuel system | Common Rail Fuel Injection |
| Rated Power | 2000 RPM |
| Torque Power | 1300 RPM |
| Specs | US | Metric |
|---|---|---|
| Horsepower | 57 HP | 42.5 kW |
| Displacement | 203 cu in. | 3319 cc |
| Bore and Stroke | 3.9×4.3 in. | 9.8×11.0 cm |
| Coolant Capacity | 2.6 gal | 9.7 L |
| Engine Oil Capacity | 3.2 gal | 12.3 L |
| Fuel Capacity | 31.7 gal | 120.0 L |
Engine Dimensions
| US | Metric | |
|---|---|---|
| Length | 31.1 in. | 79.0 cm |
| Width | 24.1 in. | 61.3 cm |
| Height | 38.9 in. | 98.7 cm |
Engine Weight
| US | Metric | |
|---|---|---|
| Dry Weight | 595 Ibs | 270 kg |
John Deere 85g Lifting Capacity
| Load Point Height | Over Front | Over Side |
|---|---|---|
| 4.5 m (15 ft.) | 3825 lbs 1735 kg | 3702 lbs 1679 kg |
| 3.0 m (10 ft.) | 4506 lbs 2044 kg | 3572 lbs 1620 kg |
| 1.5 m (5 ft.) | 5773 lbs 2619 kg | 3332 lbs 1511 kg |
| Ground Line | 2992 lbs 6597 kg | 3143 lbs 1426 kg |
| –1.5 m (–5 ft.) | 6322 lbs 2868 kg | 3087 lbs 1400 kg |
John Deere 85g Weight
| US | Metric | |
|---|---|---|
| Operating Weight | 19,564 lbs | 8874 kg |
Depending on the blade size, rubber belt, and grouser shoe options, the John Deere 85g weight will change.
Performance
| US | Metric | |
|---|---|---|
| Arm Digging Force | 7,981 lb. | 35.5 kN |
| Bucket Digging Force | 10,476 lb. | 46.6 kN |
| Maximum Reach | 164 in. | 721 cm |
| Maximum Digging Depth | 234 in. | 399 cm |
| Maximum Cutting Height | 267 in. | 679 cm |
| Maximum Dumping Height | 188 in. | 477 cm |
| Minimum Swing Radius | 108 in. | 274 cm |
| Maximum Vertical Wall | 137 in. | 347 cm |
| Tail Swing Radius | 59 in. | 149 cm |
The performance of the John Deere 85g was measured by an arm length of 162 cm.
Travel Speed
| US | Metric | |
|---|---|---|
| Low Speed | 1.9 mph | 3.1 km |
| High Speed | 3.1 mph | 5.0 km |
Hydraulic system
| US | Metric | |
|---|---|---|
| Pump Flow (x2) | 19 GPM 15 GPM | 72 LPM 56 LPM |
| Auxiliary Flow | 5.3 GPM | 20 LPM |
| Hydraulic Tank | 15 gal | 56 L |
Swing System
| Swing Speed | 10.5 RPM |
| Left | 60° |
| Right | 60° |
Dimensions
| US | Metric | |
|---|---|---|
| O/A Lenght | 261 in. | 664 cm |
| O/A Height | 103 in. | 261 cm |
| Cab Height | 100 in. | 253 cm |
| Ground Clearance | 13 in. | 34 cm |
| Blade Height | 18 in. | 46 cm |
| Blade Width 18 in. 45 cm Shoes | 87 in. | 220 cm |
| Track Width | 18 in. | 45 cm |
Undercarrige
| US | Metric | |
|---|---|---|
| Undercarriage Width 18 in. 45 cm Shoes | 89 in. | 220 cm |
| Track Width | 18 in. | 45 cm |
Ground Pressure
| US | Metric | |
|---|---|---|
| Rubber Crawler Pads | 6.0 psi | 41.5 kPa |
| Continuous Rubber Belt | 6.0 psi | 41.4 kPa |
| Triple Semi-Grouser Shoes | 6.0 psi | 41.3 kPa |
The John Deere 85 excavator is a medium-sized machine. It is suitable for medium-heavy tasks and confined spaces, but if you need to move lighter loads or complete tasks faster, you should consider one of the other G series models.John Deere 85g Review
