Case CX55B is an excavator that can be used for a variety of tasks. A bucket digging depth of 5 m on a backhoe loader allows you to dig deep holes for foundations or trenches for drainage pipes or cables.
Because of its efficient hydraulics system and optimized engine power management technology, the Case CX55B backhoe provides exceptional performance while consuming little fuel.
Case Cx55b Specs
Brand | Case |
Model | CX55B |
Type | Mini excavator |
Years Made | 2011-2017 |
Engine
Brand | Yanmar |
Model | 4TNV88-C-PYB |
Type | Diesel |
No. of Cylinders | 4 |
Emission | Final tier 4 |
Aspiration | Naturally |
Fuel Filter | Full flow |
Measured Power | 2400 RPM |
Torque Power | 1440 RPM |
Starter | 12 V |
Alternator | 55 amp |
Specs | US | Metric |
---|---|---|
Horsepower | 37.4 HP | 27.9 kW |
Displacement | 133.6 cu in. | 2189 cc |
Engine Torque | 97.2 Ib-ft | 131.8 Nm |
Bore | 3.4 in. | 8.6 cm |
Stroke | 3.5 in. | 8.9 cm |
Radiator | 1.6 gal | 6.0 L |
Engine Oil Capacity | 2.0 gal | 7.4 L |
Fuel Tank Capacity | 19.8 gal | 75.0 L |
Engine Dimensions
Dimension | US | Metric |
---|---|---|
Length | 30.7 in. | 78.1 cm |
Width | 21.3 in. | 54.1 cm |
Height | 28.5 in. | 72.4 cm |
Engine Weight
US | Metric | |
---|---|---|
Weight | 375 Ibs | 170 kg |
Performance
US | Metric | |
---|---|---|
Bucket Digging Force | 11130 lbs | 49.4 kN |
Arm Digging Force | 5300 lbs | 23.6 kN |
Max. Dig Radius | 20 ft 6 in. | 624 cm |
Max. Dig Depth | 12 ft 10 in. | 390 cm |
Dump Height | 14 ft 3 in. | 435 cm |
Overall Reach Height | 19 ft 5 in. | 593 cm |
Travel Speed
Gear | US | Metric |
---|---|---|
1st | 1.4 mph | 2.2 km |
2nd | 2.5 mph | 4.0 km |
Hydraulic System
US | Metric | |
---|---|---|
Rated Flow | 13.2 GPM | 49.9 LPM |
Auxiliary flow | 13.2 GPM | 49.9 LPM |
System Pressure | 3,336 psi | 230 Bar |
Hydraulic Tank | 15.2 gal | 57.7 L |
Dimensions
US | Metric | |
---|---|---|
Overall Height | 8 ft 4 in. | 253 cm |
Overall Length | 18 ft 1 in. | 550 cm |
Width of Upper Structure | 6 ft 4 in. | 194 cm |
Ground Pressure | 4.35 psi | 30.0 kPa |
Weight
US | Metric | |
---|---|---|
Operating Weight | 11300 lbs | 5130 kg |
Case CX55B is a compact excavator that can be used for a variety of tasks. It has excellent handling, low fuel consumption, and is simple to maintain.Case Cx55B Reviews
Performance
Features
Reliability
Drive
Price
The information presented here will help you decide if this product is the best fit for your situation. Though we do our best to provide all the information you need, things can always change. So be sure to do your own research before purchasing a vehicle, because the information in this review may become outdated over time. If you would like exact details, please contact the vendor directly. If you need Case Cx55b manual, please specify by commenting.
