John Deere 855 Specifications
| Brand | John Deere |
| Model | 855 |
| Type | Utility tractor |
| Series | 500 |
| Years Made | 1986-1998 |
Engine Specs
| Brand | Yanmar |
| Model | 3TN75RJ |
| Type | Diesel, water-cooled |
| No. of Cylinders | 3 |
| Rated Speed | 3200 RPM |
| Operating Range | 1400-3425 RPM |
| Combustion | Indirect Injection, electric shutoff |
| Aspiration | Natural |
| Lubrication | Pressured |
| Air Cleaner | Dry type with safety element key |
| Emission | EU Stage V, EPA Tier IV Final, Lower Regulated Countries |
| Compression Ratio | 17.8:1 |
| Starter | 12V electric |
| US | Metric | |
|---|---|---|
| Net Power | 23.9 HP | 17.8 kW |
| PTO Power | 19 HP | 14.2 kW |
| Engine Torque at Rated Speed | 39 Ib-ft | 58 Nm |
| Displacement | 60.7 cu in. | 995 cc |
| Bore and Stroke | 2.95 x 2.95 in. | 7.5×7.5 cm |
| Fuel Tank Capacity | 6.6 gal | 25 L |
| Cooling System | 1.2 gal | 4.5 L |
| Starter Size | 1.3 HP | 1.0 kW |
| 75% load mowing (hour) | 0.79 gal | 3 L |
Transmission
| Transmission | Hydrostatic, 2-range (forward/reverse) |
| Transaxle Speed Ranges | High/Lo |
| No. of Speeds | Infinite |
| US | Metric | |
|---|---|---|
| Transmission Oil Capacity | 4.5 gal | 17 L |
Travel Speed
| Gear | US | Metric |
|---|---|---|
| Forward-Low | 6.0 mph | 9.7 km |
| Forward-High | 11.0 mph | 17.7 km |
| Reverse-Low | 3.0 mph | 4.8 km |
| Reverse High | 5.7 mph | 9.2 km |
Power Take-Off (PTO)
| Type | Live Independent |
| Clutch | Hydraulic, Multi-Disk |
| Brake | Hydraulically Controlled |
| Speed Mid 1:1 Ratio | 2100 RPM |
| Speed Rear 1:3 Ratio | 540 RPM |
Dimensions
| Dimension | US | Metric |
|---|---|---|
| Width | 42.6 in. | 108.2 cm |
| Length | 96.0 in. | 243.8 cm |
| Height to Hood | 52.3 in. | 132.8 cm |
| Height to ROPS | 75.5 in. | 191.8 cm |
| Wheelbase | 64.0 in. | 162.6 cm |
| 2WD Ground Clearance | 12.7 in. | 32.3 cm |
| MFWD Ground Clearance | 9.9 in. | 25.1 cm |
Tire Size
| 2WD Standard Tires – Front | 4.00×15 |
| 2WD Standard Tires – Rear | 9.5×16 |
| MFWD Standard Tires – Front | 6-12 |
| MFWD Standard Tires – Rear | 9.5×16 |
Weight
| Model | US | Metric |
|---|---|---|
| 2WD | 812 lbs | 1790 kg |
| MFWD | 848 lbs | 1870 kg |
Performance
| US | Metric | |
|---|---|---|
| Lift Capacity – Early Models | 785 lbs | 357 kg |
| Late Models – SN 180450 | 1005 lbs | 456 kg |
| Pump Capacity | 5.6 gpm | 3.78 lpm |
| Hydraulic Working Pressure | 2050 psi | 14135 kPa |
Attachments
- Mower Deck
- Blade
- Loader
- Backhoe
John Deere 2734M Mower Deck
| Brand | John Deere |
| Model | 2734M |
| Type | Mid-mount mower deck |
| No. of Blade | 3 |
| Lift | Hydraulic |
| US | Metric | |
|---|---|---|
| Cutting Width | 60 in. | 152.4 cm |
| Cut Height | 1.5 to 7.8 in. | 3.8 to 19.8 cm |
| Overall Width | 72.5 in. | 184.2 cm |
| Weight | 325 lbs | 147.4 kg |
John Deere 2733M Mower Deck
| Brand | John Deere |
| Model | 2733M |
| Type | Mid-mount mower deck |
| No. of Blade | 3 |
| Lift | Hydraulic |
| US | Metric | |
|---|---|---|
| Cutting Width | 72 in. | 182.9 cm |
| Cut Height | 1.5 to 8.6 in. | 3.8 to 21.8 cm |
| Overall Width | 85 in. | 215.9 cm |
| Weight | 448 lbs | 203.2 kg |
John Deere 2780M Blade
| Brand | John Deere |
| Model | 2780M |
| Type | Blade, front-mount |
| No. of Blade | 3 |
| Lift | Hydraulic |
| Angle | Hydraulic |
| US | Metric | |
|---|---|---|
| Width | 54 in. | 137.2 cm |
| Height | 18 in. | 45.7 cm |
| Lift Height | 11 in. | 28.0 cm |
| Cut Depth | 5 in. | 12.7 cm |
| Weight | 215 lbs | 97.5 kg |
John Deere 380M Blade
| Brand | John Deere |
| Model | 380M |
| Type | Blade, front-mount |
| No. of Blade | 3 |
| Lift | Hydraulic |
| Angle | Hydraulic |
| US | Metric | |
|---|---|---|
| Width | 54 in. | 137.2 cm |
| Height | 18 in. | 45.7 cm |
| Lift Height | 13 in. | 33.0 cm |
| Cut Depth | 5.5 in. | 14.0 cm |
| Weight | 450 lbs | 204.1 kg |
John Deere 70A Loader
| Brand | John Deere |
| Model | 70A |
| Type | Loader |
| Dump Angle | 45° |
| US | Metric | |
|---|---|---|
| Dumped Bucket Clearance | 62 in. | 157.5 cm |
| Dump Reach | 27.5 in. | 69.9 cm |
| Height to Pin | 77.3 in. | 196.3 cm |
| Level Bucket Clearance | 73.8 in. | 187.5 cm |
| Reach at Ground | 47.8 in. | 121.4 cm |
| Lifting Force | 1300 lbs | 589.7 kg |
| Bucket Force | 1570 lbs | 680.4 kg |
John Deere 7 Backhoe
| Brand | John Deere |
| Model | 7 |
| Type | Backhoe |
| US | Metric | |
|---|---|---|
| Digging Depth | 90.0 in. | 228.6 cm |
| Height | 70.0 in. | 177.8 cm |
| Reach From Pivot | 114.0 in. | 289.6 cm |
| Dipperstick Force | 1100 lbs | 499 kg |
| Bucket Force | 1945 lbs | 882.2 kg |
While I have only owned this mower for a year the few times I have had to use it, its stellar performance has made me take the time to write my first product review. I have had zero problems with this machine, and the performance is superb. I own several implements to handle landscaping, mowing, clearing brush and snow removal and more. This is a reliable and versatile machine that delivers an impressive performance. I think you will like it.
John Deere 855 Review
Performance
Features
Power
Attachment Options
Price
The information presented here will help you decide if this product is the best fit for your situation. Though we do our best to provide all the information you need, things can always change. So be sure to do your own research before purchasing a vehicle, because the information in this review may become outdated over time. If you would like exact details, please contact the vendor directly.
