John Deere 450J specs, weight, years made you will find a review of the 450J John Deere by our experts. Scroll down without wasting time.
John Deere 450j Specs
| Manufacturer | John Deere |
| Model | 450J LT |
| Type | Crawler Dozer |
| Years Made | 2005-2021 |
Serial Numbers
| 2012 John Deere 450J | 1T0450JXCCD218543 |
| 2013 John Deere 450J | 1T0450JXLDD244962 |
| 2006 John Deere 450J | T0450JX122857 T0450JX118566 T0450JX132665 |
| 2014 John Deere 450J | 1T0450JXPDD255144 |
| 2015 John Deere 450J LGP | 1T0450JXPFD280676 1T0450JXAFD280202 |
| 2006 John Deere 450J LGP | T0450JX118911 131070 T0450JX131497 T0450JX118566 T0450JX132665 |
| 2014 John Deere 450J LGP | 1T0450JXADD252865 1T0450JXPDD255144 |
| 2013 John Deere 450J LGP | TDD246037 247570 |
| 2012 John Deere 450J LGP | 1T0450JXVCD222133 1T0450JXCCD218543 |
| 2011 John Deere 450J LGP | TU208269 0201720 |
| 2007 John Deere 450J LGP | X141679 |
| 2005 John Deere 450J LGP | TO450JX113893 |
| 2015 John Deere 450J LT | 1T0450JXCFD283159 1T0450JXEFD282441 |
| 2013 John Deere 450J LT | 1T0450JXVDD244490 |
| 2008 John Deere 450J LT | T0450JX165877 |
| 2006 John Deere 450J LT | TO450JX125664 T0450JX125099 |
| 2005 John Deere 450J LT | T0450JX117234 |
Engine
| Manufacturer | John Deere |
| Model | 4045H |
| Series | PowerTech E |
| Emission | EPA Tier 3/EU Stage IIIA |
| Type | Diesel |
| No. of Cylinders | 4 |
| Aspiration | Turbocharger with charge air cooler |
| Air Cleaner | Dry-type |
| Rated Measured | 2200 RPM |
| US | Metric | |
|---|---|---|
| Net Power @2200 RPM | 77 HP | 57 kW |
| Net Torque @1200 RPM | 251 lb-ft. | 341 N-m |
| Displacement | 276 cu. in. | 4.5 L |
| Bore and Stroke | 4.2×5.0 in. | 10.6×12.7 cm |
Transmission
| Type | Hydrostatic |
| No of Gear | 2 |
Travel Speed
| Gear | US | Metric |
|---|---|---|
| Forward | 5.5 mph | 8.0 km |
| Reverse | 5.5 mph | 8.0 km |
Dimensions
| US | Metric | |
|---|---|---|
| Overall Height with ROPS | 108 in. | 274 cm |
| Overall Length | 190 in. | 480 cm |
| Blade Lift Height | 30.4 in. | 77.2 cm |
| Blade Digging Depth | 20.8 in. | 52.8 cm |
| Width Over Tracks | 73.2 in. | 185.4 cm |
Weight
| Weight | US | Metric |
|---|---|---|
| Operating Weight | 16316 lbs | 7400 kg |
Undercarrige
| Weight | US | Metric |
|---|---|---|
| Track Length on Ground | 86 in. | 218.4 cm |
| Ground Pressure | 5.90 psi | 40.7 kPa |
| Ground Contact Area | 2,752 sq. in. | 17,755 cm² |
| Track Pitch | 6.3 in. | 16 cm |
Attachments
Blade Specs
| US | Metric | |
|---|---|---|
| Width | 97 in. | 246.4 cm |
| Height | 38 in. | 95.5 cm |
| Width Over Track | 73 in. | 185.4 cm |
| Cut Reach | 2.2 in. | 5.6 cm |
| Cast Reach | 12.5 in. | 31.8 cm |
| Tilt | 13.3 in. | 33.8 cm |
| Angled Width | 88 in. | 222.5 cm |
| Blade Angle | 25.4° | 25.4° |
| SAE Capacity | 2.14 cu. yd | 1.64 m³ |
Ripper Specs
| US | Metric | |
|---|---|---|
| Winch Length | 30.0 in. | 75.2 cm |
| Maximum Clearance Under Tip | 20 in. | 50.8 cm |
| Maximum Penetration | 20 in. | 50.8 cm |
| Overall Length Lowered Position | 57 in. | 145 cm |
| Overall Length Raised Position | 40 in. | 101.5 cm |
| Overall Beam Width | 72 in. | 183 cm |
| Ripping Width | 66 in. | 167 cm |
| Slope Angle (full raise) | 40° | 40° |
The JD450J and Cat D3 are essentially the same sizes. However, the D5G will likely have about 20 or 25 hp more than the Deere. If you want a Deere, the 450J is cheaper than comparable Caterpillar dozers.
John Deere 450 Review
Performance
Features
Reliability
Drive
Price
The information presented here will help you decide if this product is the best fit for your situation. Though we do our best to provide all the information you need, things can always change. So be sure to do your own research before purchasing a vehicle, because the information in this review may become outdated over time. If you would like exact details, please contact the vendor directly.
