The Cat 313E excavator boasts a powerful engine, advanced diagnostics, and durability, all designed for high production. Its lightweight design allows for better maneuverability and reduced fuel consumption. The standard hydraulics package offers reliability and improved performance in various applications. This excavator is suitable for various job sites, including demolition, infrastructure, and quarrying, thanks to its improved boom design, variable-force hydraulics, and integrated control systems.
Cat 313 Specs
| Brand | Caterpillar |
| Model | 313 |
| Type | Hydraulic excavator |
| Years Made | 2020-Today |
Engine
| Brand | Cat |
| Model | C3.6 |
| Type | Diesel |
| No. of Cylinders | 4 |
| Emissions | Tier 4 Final, EU Stage V |
| Aspiration | Turbocharged |
| Combustion | Direct Injection |
| Aftertreatment | DOC+DPF or DOC+DPF+SCR |
| Compression Ratio | 17.0:1 |
| Rated Speed | 2200 RPM |
| US | Metric | |
|---|---|---|
| Horsepower | 110 HP | 82 kW |
| Displacement | 220 cu in. | 3.6 L |
| Bore and Stroke | 3.9×4.7 in. | 9.9×11.9 |
| Max. Torque | 406 Ib-ft | 550.5 Nm |
Engine Dimensions
| US | Metric | |
|---|---|---|
| Length | 26.3 in. | 66.7 cm |
| Width | 22.2 in. | 56.4 cm |
| Height | 31 in. | 78.7 cm |
Engine Weight
| US | Metric | |
|---|---|---|
| Engine Dry Weight | 840 lbs | 381 kg |
Capacity
| US | Metric | |
|---|---|---|
| Fuel Capacity | 68 gal | 258 L |
| Engine Oil Capacity | 4 gal | 15 L |
| Coolant Capacity | 2.1 gal | 8 L |
Performance
| US | Metric | |
|---|---|---|
| Maximum Digging Depth | 238 in. | 604 cm |
| Max. Reach Ground Level | 341 in. | 866 cm |
| Max. Cutting Height | 348 in. | 883 cm |
| Max. Loading Height | 253 in. | 642 cm |
| Min. Loading Height | 63 in. | 160 cm |
| Bucket Digging Force | 22,180 lbf | 98.7 kN |
| Stick Digging Force | 13,330 lbf | 59.3 kN |
| Boom Reach | 183 in. | 465 cm |
| Stick Reach | 118 in. | 300 cm |
| Bucket Capacity | 0.69 m³ | 0.53 m³ |
Hydraulic System
| US | Metric | |
|---|---|---|
| Maximum Flow | 65 GPM | 247 LPM |
| Maximum Pressure (equipment) | 5075 psi | 350 Bar |
| Hydraulic System (including tank) | 38 gal | 145 L |
Swing System
| Swing Speed | 11.5 RPM |
| Swing Torque | 35 kN-m 25,741 lbf-ft |
Cat 313 Weight
| US | Metric | |
|---|---|---|
| Max. Operating Weight | 30,400 lbs | 13,800 kg |
Dimensions
| US | Metric | |
|---|---|---|
| Cab Height | 111 in. | 281 cm |
| Shipping Length with Blade | 318 in. | 805 cm |
| Track Width with 20 in. shoes | 98 in. | 249 cm |
| Tail Swing Radius | 86 in. | 219 cm |
| Counterweight Clearance | 36 in. | 92 cm |
| Ground Clearance | 17 in. | 44 cm |
The Cat 313 is a compact, powerful, and fuel-efficient excavator from a 60-year-old company. It's ideal for small jobs and features an adjustable seat, comfortable armrests, and an easy-to-access cab with wide windows. Caterpillar 313 competes with Komatsu PC138US-11, Hitachi ZX130-6, Volvo ECR145E, John Deere 135G, Doosan DX140LCR-5, Bobcat E145, and Yanmar ViO80.Cat 313 Review
Reliability
Specifications
Performance
Drive
Price
The information presented here will help you decide if this product is the best fit for your situation. Though we do our best to provide all the information you need, things can always change. So be sure to do your own research before purchasing a vehicle, because the information in this review may become outdated over time. If you would like exact details, please contact the vendor directly. If you need Cat 313 manual, please specify by commenting.
