Using the Cat 257B in various projects allowed me to appreciate its combination of practicality and power. This compact loader proved itself to be a dependable and efficient machine, handling diverse tasks with ease. The 57 HP diesel engine offers impressive strength, and the advanced hydraulic system ensures precise control in demanding conditions. Its rubber track system provides excellent traction on soft or uneven surfaces, reducing ground impact; ideal for jobs that require minimal disturbance to the terrain. The versatility of the vertical lift mechanism and compatibility with numerous attachments make it a true workhorse for a variety of applications.
The operator-focused cabin is designed for comfort and functionality, featuring intuitive controls and exceptional visibility. Maintenance is straightforward, with easy access to critical components, and the machine’s durability is evident even after prolonged use in tough conditions. Whether tackling heavy-duty construction tasks or more delicate landscaping projects, the Caterpillar 257B consistently delivers reliable and efficient performance, making it a standout choice for professionals in need of a versatile multi-terrain loader.
Cat 257B Specs
| Manufacturer | Cat |
| Model | 257B |
| Type | Multi Terrain Loaders |
| Years Made | 2004-2014 |
| Lift Arms | Vertical Lift Linkage |
Engine
| Manufacturer | Caterpillar |
| Model | 3024C |
| Type | 4 stroke liquid cooled |
| Injector Type | Direct injection |
| Emissions | Tier 2 / Stage 3 |
| No of Cylinders | 4 |
| Aspiration | Turbocharged |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 62 HP | 46 kW |
| Net Power | 57 HP | 43 kW |
| Displacement | 134 cu. in. | 2196 cc |
| Bore | 3.3 in. | 8.4 cm |
| Stroke | 3.9 in. | 10.0 cm |
Fluid Capacity
| US | Metric | |
|---|---|---|
| Engine Oil | 1.8 gal | 7.0 l |
| Coolant Capacity | 2.6 gal | 10.0 l |
| Fuel Tank | 20 gal | 77 l |
Performance
| Metric | US | |
|---|---|---|
| Rating Operating Capacity (35% Tipping) | 620 kg | 1367 lbs |
| Rating Operating Capacity (50% Tipping) | 732 kg | 1615 lbs |
| Rated Operating Capacity 35% (HF) | 738 kg | 1627 lbs |
| Rated Operating Capacity 50% (HF) | 1054 kg | 2324 lbs |
| Tilt Breakout Force | 1693 kg | 3732 lbs |
| Lift Breakout Force | 1670 kg | 3683 lbs |
| Operating Weight | 3428 kg | 7559 lbs |
| Operating Weight (HF) | 3470 kg | 7651 lbs |
| Max. Travel Speed (high range) | 11.4 kmh | 7.5 mph |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 15.6 GPM | 60 LPM |
| Optional High Flow | 26.0 GPM | 100 LPM |
| Main System Relief | 3035 psi | 209 Bar |
Dimensions
| in. | cm | |
|---|---|---|
| Max. Operating Height | 156 | 396.3 |
| Height to Hinge Pin | 119 | 301.8 |
| Dump Height | 90 | 227.8 |
| Dump Reach | 54.6 | 138.8 |
| Height to Cab | 80 | 202.2 |
| O/A Lenght with Bucket | 137 | 349.0 |
| O/A Width | 66 | 167.6 |
| Ground Clearance | 10 | 25.7 |
