Bobcat T590 delivers the maximum performance for the most challenging jobs, help you keep your promises to customers. The T590 Bobcat is a strong, durable design, innovative technology, and rugged construction means you can handle the toughest jobs. No matter how tough the job, the Bobcat T590 skid steer is rugged enough to handle it.
Bobcat T590 Specs
| Brand | Bobcat |
| Model | T590 |
| Series | 500 Series |
| Type | Compact track loader |
| Years Made | 20113-2020 |
Bobcat T590 horsepower is 66 Hp.
The Bobcat T590 weighs 7750 pounds.
The Bobcat T590 is priced between $30,000 and $60,000.
The main distinctions between the Bobcat T590 and T595 are horsepower and operating capacity.
Bobcat T590 Engine
Powered by the Kubota V2607-DI-T-E3B-BC-1 engine, the Bobcat T590 is a compact skid loader that delivers enough torque and power to get your jobs done.
| Brand | Kubota |
| Model | V2607-DI-T-E3B-BC-1 |
| Type | Diesel, turbocharged, water cooling |
| No. of Cylinders | 4 |
| Emissions | Stage V |
| Rotation | Counter-clockwise |
| Fuel System | In-line pump |
| Combustion Chamber | Direct injection |
| Rated Speed | 2700 RPM |
| Torque Speed | 1600 RPM |
| US | Metric | |
|---|---|---|
| Horsepower | 66.0 HP | 49.2 kW |
| Displacement | 159.6 cu in. | 2615 cc |
| Bore and Stroke | 3.43×4.33 in. | 8.7×11.0 cm |
| Maximum Torque | 162.5 lb-ft | 220.3 Nm |
| Fuel Tank Cap. | 36.5 gal | 138.2 L |
| Engine Oil Capacity | 2.69 gal | 10.2 L |
| Alternator Capacity | 12V | 60 A |
| Starter Capacity | 12 V | 12 kW |
Engine Dimensions
| Dimension | US | Metric |
|---|---|---|
| Length | 24.5 in. | 62.3 cm |
| Width | 18.9 in. | 48.1 cm |
| Height | 26.9 in. | 68.2 cm |
Engine Weight
| Weight | US | Metric |
|---|---|---|
| Dry Weight | 518 Ibs | 235 kg |
Performance
The Bobcat T590 is small enough to operate in tight areas and tough enough to help you get through the toughest jobs. Innovative new features have been added to the T590 Bobcat to maximize your ability to get the job done right.
| US | Metric | |
|---|---|---|
| Lifting Capacity | 2187 lbs | 992 kg |
| Tipping Load | 6248 lbs | 2834 kg |
| Pump Capacity | 17.1 gal | 64.7 L |
| System Relief at Quick Couplers | 3.45 to 355 psi | 23.8 to24.5 MPa |
| Pump capacity with High Flow (optional) | 26.7 gal | 101.1 L |
Transmission
The Bobcat T590 features two fully reversing hydrostatic motors that are powered by infinitely variable tandem hydrostatic piston pumps.
| Transmission | Hydrostatic |
| No. of Speed | Infinite |
| Gear | 2 |
Travel Speed
| Gear | US | Metric |
|---|---|---|
| 1 | 6.3 mph | 10.1 km |
| 2 | 10.4 mph | 16.7 km |
Dimensions
| US | Metric | |
|---|---|---|
| Length | 104.6 in. | 265.7 cm |
| Length with bucket | 133.0 in. | 337.8 mm |
| Max. Operating Height | 153..6 in. | 390.1 cm |
| Height with Operator Cab | 77.6 in. | 197.2 cm |
| Height to Bucket Hinge Pin | 119.0 in. | 302.3 cm |
| Bucket Width | 68.0 in. | 172.7 cm |
| Width Over Tracks | 67.1 in. | 170.4 cm |
| Ground Clearance | 17.7 in | 24 cm |
Weight
| Us | Metric | |
|---|---|---|
| Operating Weight | 7750 lbs | 3515 kg |
| Shipping Weight | 6935 lbs | 3146 kg |
Bobcat T190 vs T590
Bobcat’s t190 and t590 have been designed specifically to handle the demands of the construction industry. Exciting in more ways than one, the T190 and T590 are worthy additions to the Bobcat lineup. The Bobcat T190 vs T590 comparison by Bobcat will be featured below.
| Performance | T590 | T190 |
|---|---|---|
| Lifting Capacity | 2187 lbs/992 kg | 1900 lbs/861 kg |
| Tipping Load | 6248 lbs/2834 kg | 7283 lbs/3303 kg |
| Height to Hinge Pin | 119 in./302 cm | 118 in./300 cm |
| Operating Weight | 7750 lbs/3515 kg | 7775 lbs/3526 kg |
| Bucket Width | 68 in./172.7 cm | 68 in./172.7 cm |
| Cab Height | 77.6 in./197.2 cm | 76.3 in/193.8 cm |
| Max. Travel Speed | 10.4 mph/16.7 km | 7.3 mph/11.7 km |
| Horsepower | 66 HP/49.2 kW | 66 HP/49.2 kW |
| Fuel Tank Capacity | 36.5 gal/138.2 L | 28 gal/106 L |
Bobcat T590 vs T595
While the T590 and T595 are both designed to be used on construction sites, the T595 is slightly larger than the T590.
| Performance | T590 | T595 |
|---|---|---|
| Lifting Capacity | 2187 lbs/992 kg | 2280 lbs/1034 kg |
| Tipping Load | 6248 lbs/2834 kg | 6517 lbs/2956 kg |
| Height to Hinge Pin | 119 in./302 cm | 119 in./302 cm |
| Operating Weight | 7750 lbs/3515 kg | 8022 lbs/3639 kg |
| Bucket Width | 68 in./172.7 cm | 68 in./172.7 cm |
| Cab Height | 77.6 in./197.2 cm | 77.8 in./197.5 cm |
| Max. Travel Speed | 10.4 mph/16.7 km | 7.1 mph/11.5 km |
| Horsepower | 66 HP/49.2 kW | 70 HP/52.2 kW |
| Fuel Tank Capacity | 36.5 gal/138.2 L | 36.5 gal./138.2 L |
Bobcat T590 Price
| Model | Hour | Price |
|---|---|---|
| 2013 Bobcat T590 | 2500 | $25,000 |
| 2014 Bobcat T590 | 500 | $33,000 |
| 2015 Bobcat T590 | 500 | $37,000 |
| 2016 Bobcat T590 | 2000 | $30,000 |
| 2017 Bobcat T590 | 500 | $45,000 |
| 2018 Bobcat T590 | 500 | $50,000 |
| 2019 Bobcat T590 | 500 | $52,500 |
| 2020 Bobcat T590 | 500 | $55,000 |
| New Bobcat t590 | 0 | $65,000 to $72,000 |
Bobcat T590 will open the door to new work possibilities, increase productivity and help you get more done. It’s the ideal tool for landscapers, construction workers and homeowners.Bobcat T590 Review
