Bobcat 418 mini excavator has the specs you need to be more comfortable, go through narrower openings, and work in tighter spaces with confidence. This mini excavator has superior lifting capabilities for its size class and can be equipped with a variety of attachments to increase versatility. The 418 Bobcat is powered by a diesel engine that delivers outstanding performance and dependability.
Bobcat 418 Mini Excavator Specs
Manufacturer | Bobcat |
Model | 418 |
Type | Mini excavator |
Years Made | 2008-2016 |
Engine
Brand | Kubota |
Model | D722 |
Type | Diesel, water-cooled |
No. of Cylinders | 3 |
Direction of Rotation | Counter-clockwise |
Combustion | Spherical type (ETVCS) |
Lubrication | Above CD grade |
Injection Pump | Bosch MD type mini pump |
Compression Ratio | 23.5:1 |
Firing Order | 1-2-3 |
Starter | 12V electric |
Fuel Type | Diesel fuel No. 2-D |
Rated Speed | 2000 RPM |
Max. Bare Speed | 3800 RPM |
Min. Bare Speed | 800 to 900 RPM |
US | Metric | |
---|---|---|
Horsepower | 10 HP | 7.4 kW |
Displacement | 43.9 cu in. | 719 cc |
Bore and Stroke | 2.64×2.68 in. | 6.7×6.8 cm |
Fuel Tank Capacity | 4.2 gal | 16.0 L |
Engine Oil Capacity | 1.0 gal | 3.8 L |
Coolant Capacity | 0.8 gal | 3.1 L |
Performance
US | Metric | |
---|---|---|
Arm Digging Force | 1248 lbf | 5550 N |
Bucket Digging Force | 1866 lbf | 8300 N |
Maximum Dig Depth | 71 in. | 180 cm |
Max Dump Height | 71 in. | 180 cm |
Maximum Reach | 122 in. | 310 cm |
Drawbar Pull | 2220 lbf | 9900 N |
Max. Speed | 1.7 mph | 2.8 km |
Slew System
Boom swing Left | 67° |
Boom swing Right | 64° |
Swing Speed | 9.0 RPM |
Hydraulic System
Type | Gear Pump |
US | Metric | |
---|---|---|
Auxiliary Flow | 5.3 gpm | 20 lpm |
Auxiliary Relief | 2750 psi | 190 Bar |
Dimensions
US | Metric | |
---|---|---|
Length | 110 in. | 279 cm |
Width | 28 in. | 71 cm |
Height | 83 in. | 211 cm |
Track
US | Metric | |
---|---|---|
Width | 7.1 in | 18 cm |
Overall Width Expanded | 43 in. | 110 cm |
Ground Pressure | 4.3 psi | 29.7 kPa |
Weight
US | Metric | |
---|---|---|
Operating Weight | 2600 lbs | 1176 kg |
The Bobcat 418 weight above is outfitted with a canopy, rubber tracks, and a standard bucket.
The 418 mini excavator is capable of a wide range of tasks, including landscaping, general construction, utility work, and home improvement projects. Because of its small size, it is ideal for landscapers who need to grade around existing trees, dig holes for installing fences or decks, or load material into a truck.Bobcat 418 Reviews
