Case 450 dozer’s design allows for superior low-pressure digging performance resulting in a lower overall operating pressure and increased earth displacement. Low-pressure digging meets high-power torque, operating capacity, and stability. Case 450 dozer has undergone extensive improvements in design and technology. The Track-Type Low-Pressure Digging (LPD) machine is the perfect solution if you are looking for a low operating cost, high performance, high displacement machine. Case 450 meets all your tough demands with its exceptional digging power and stability.

Case 450 dozer brings unmatched ease of operation to the job site with one key that switches from machines with different attachments. The dual-mode guidance system offers the accuracy of a tie rod steer and the simplicity of a self-leveling blade. 450 case dozer weighs 8400kg in transport configuration allowing for single-person transport. Case 450 dozer is easy to operate.

The Standard cab is also available with an air ride suspension seat, tilt/telescopic steering wheel, radio/CD/MP3 options, and a heated windshield. 450 dozer ROPS/FOPS cab with auto transmission. Optional equipment included. The oil and hydraulic fluid fill points are all located at the rear of the machine behind a normal panel. This makes it easy to keep on top of your routine maintenance.

Powered by the 534D engine, the Tier 4 Final Case 450 dozer will provide the power to conquer any job, anywhere. The result is a powerful, reliable machine with low fuel consumption and minimal downtime, making the CASE 450 faster to get into.

Case 450 Dozer Specs

OPERATOR ENVIRONMENT

• ROPS/FOPS Level 1 canopy w/ side screens
• Keyed start ignition
• Tilt ROPS/FOPS
• Rear window w/ emergency escape
• Suspension Seat, vinyl w/ 2 in (51 mm) retractable 3 point lap seat belt
• Hand and foot throttles
• Alarm package – back-up and horn
• Rearview mirror
• Headliner
• Dome Light
• Top window
• Cup holder
• 12V Power plug socket
• Foot rest
• Seat pocket
• Padded seat bar w/ integral armrests
• Loader control lockout system
• Electric parking brake control
• Operator’s compartment floor cleanout
• Proportional auxiliary hydraulic control – on joystick
• Advanced Instrument Cluster w/ digital hour meter, tachometer, Fuel level LCD bar graph w/ alarm, diagnostic features and security lockout
• Warning lights with alarms: Engine coolant temperature, Engine oil pressure, Engine malfunction, Hydraulic charge pressure, Hydraulic filter restriction
• Hydraulic oil temperature: Critical system stop, Engine system, Hydraulic system, Electrical and diagnostic system
• Warning alarms: Battery voltage – plus display, Oil service
• Indicator light: Engine preheat, Parking brake, Seat bar reminder

DRIVETRAIN

• 2-speed hydrostatic four wheel drive
• SAHR disc parking brake

ENGINE

• FPT F5B FL413 D*C001
• 207 CID (3.4 L) Turbo
• Tier 4 Final Certified
• Selective Catalytic Reduction (SCR)
• High Pressure Common Rail (HPCR)
  • fuel injection
• Horsepower:
  • Gross: 90 hp (67 kW)
  • Net: 84 hp (63 kW)
  • Peak torque: 282 lb·ft (383 N·m)
• 160 amp alternator
• Dual element air cleaner
• Organic Acid Technology (OAT)
• Anti-freeze solution to -34º F
• Fuel tank – 25.5 gal (U.S.)
• Over and under radiator and oil cooler
• 3-stack after cooler/radiator/ oil cooler configuration
• Glow plugs
• Integral engine oil cooler
• Fuel filter with water trap
• 1,000 CCA 12V battery
• Master electrical disconnect
• Jump start terminal

LOADER

• Manual attachment coupler
• Vertical lift geometry
• Loader lift arm support strut
• SAE operating load: 3,150 lbs
• Tipping load: 9,000 lbs

HYDRAULICS

• Auxiliary hydraulics: @ 3,450 psi (238 bar) – 24.2 gpm (91.5 L/min)
• 6 micron oil filtration system
• 3-spool loader control valve
• Auxiliary hydraulic disconnects, ISO flat-face – connect-under-pressure with case drain
• Hydraulic circuit pedal lock
• Auxiliary function lockout override
• Loader lift lockout override
• Heavy-duty hydraulic oil cooler
• Loader arm float position
• Loader function lockout system

TRACKS

• Rubber Tracks

OTHER STANDARD FEATURES

• Halogen lights – 2 front, 2 side, 2 rear flood
• Heavy duty front lights
• Pre-wired for rotating beacon
• Lockable service access hood
• Single-point daily servicing
• Rear tail lights
• Heavy duty rear door
• Remote oil and fuel filters
• Block heater
• Debris ingression sealing
• Mounting points for add-on counterweights

Case 450 dozer specs are taken from the case official site.
